PDM-02 58mm mini mobile barcode bluetooth portable dot matrix printer for Andorid

FOB Price

USD $79 - $90 / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

PDM-02 58mm mini mobile barcode bluetooth portable dot matrix printer for Andorid

Product Description

Feature:

1. Mini portable bluetooth dot matrix printer

2. Dot matrix impact printing method

3. Unique rugged design withstands droping up to 1.2 meters

4. Support printing when battery in charging

5. Intelligent quick battery charging

6. Large paper capacity and long battery life

Application:

Specification:

Printing Method	Dot Matrix
Resolution	5 dots/mm(127dpi),240 dots/line
Effective Printing Width	48mm
Printing Speed	1.2 lps
Character Set	ASCII,GB2312(Chinese)
Print Font	ANK: 7 x5/12 x6/16 x8, Chinese: 12 x 12/16 x 16
Self-defined Character	Yes
Graphic	Support bitmap downloading
SDK	Android
Driver	Windows XP/Windows Vista/Windows 7
Paper End Sensor	Yes
Black Mark Location	Yes
Auto Sleeping	Yes
Interface	PDM02-BT:RS-232/USB+Bluetooth;
	PDM02-IR:RS-232/USB+Raw-IR
	PDM02: RS-232/USB
Battery	DC7.4V,2000mAh rechargeable Li-ion battery
Charger	DC12V/1A
TPH	1.5 Million lines
Paper Type	Plain paper
Paper Width	57.5± 0.5mm
Paper Thickness	0.06 to 0.08mm
Paper Roll Diameter	40mm(Max.)
Paper Supply Method	Semi-auto Loading
Paper Cutting Method	Manual
Operating Temp/Humidity	-10-50°C/10%-80%
Storage Temp/Humidity	-20-60°C / 10%-90%
Dimension	99×112.3×46(W×D×H) mm
Weight	345g (with battery,without paper roll)
