Mini Bar Refrigeraor Spare Part Bundy Tube Condenser
- SHANGHAI/NINGBO
 - T/T Credit Card

You May Like
-


Double Layer Wire Tube Condenser Supplier
 -


Refrigerator Winding Wire Tube Condenser
 -


Freezers Air-cooled Condensers For Korea Markets
 -


Water Cooler Dispenser Parts Wire Condenser
 -


1/4HP Wire And Tube Condenser For Refrigerator,Freezer,Ice Box
 -


Five Layer Wire Tube Folding Freezer Condenser For Korea Market

Product Details
| Place of Origin | Hubei, China | Brand Name | TJ | |
| Model Number | C-20 | Condition | New |
Packing in plastic bags or in standard carton box, evaporator with plastic film cover.
Product Description
Specifications
ISO9001, ROHS ,LFGB approvedSuperior supplier of Midea
30 years professional manufacturing condenser/evaporator
experience
30 years professional manufacturing condenser/evaporator experience
ROHS,ISO9001.LFGB certificate
Good supplier for Midea Refrigerator
OEM
Mini Bar Refrigeraor Spare Part Bundy Tube Condenser
Specification:
Raw material  | Rolling welded steel tube : Out Diameter 8mm , Wall Thickness 0.6-0.71mm;  |
Technical Ability  | 1)The distance of steel wire ≥6mm; 2)Produce according to the drawing or sample supplied by clients;  |
performance  | 1)Surface treated with powder painting or dip coating to prevent the corrosion 2)Inner cleanness can meet the requirement of R134a &CFC cooling system; 3)Can satisfy the cooling capability requirements; 4)Producing Capacity: 3000 pieces/Day;  |
Production capacity:  | Relying on the advanced imported equipment and the unremitting effort of all the staff of the company, the production capacity has reached 3.5 million sets or pieces a year.  |
R134a cooling system tube pamameters
Residual Moisture  | ≤20 mg/m2  |
Residual Impurity  | ≤30 mg/m2  |
Residual Mineral Oil  | ≤7 mg/m2  |
Residual Chlorine  | ≤0.3 mg/m2  |
Residual Paraffin  | ≤0.2 mg/m2  |
coating parameters
Coating Thickness  | Thickness of coating 30-100um  |
Harness of Coating  | ≥2H  |
Impact of Coating  | 50 kg/cm impact, no crack  |
Adhesion of coating  | ≥two grade  |
Flexibility of Coating  | Around R=3D bend 180, no crack or no fall off  |
Color tolerance of Power Painting  | E≤1.5  |
More products catalog for your reference:
Wire tube condenser  | A.Flat type: 1. 6U/7U/8U/11U/12U/14U wire tube condenser 2. 17rows,21rows,23rows wire tube condenser  |
B. Monolayer flat wire tube condenser  | |
C. Double layer flat wire tube condenser  | |
D. Winding type wire tube condenser  | |
Wire tube evaporator  | A. Two layer/sheet wire tube condenser  |
B.Three layer wire tube condenser  | |
C.Four layer wire tube condenser  | |
D.Seven layer wire tube condenser  | |
Fin Aluminum evaporator  | /  |
Fin Aluminum Condenser  | /  |
Tube plate evaporator  | /  |
Professional manufacturer for condenser and evaporator:
Professional factory:  | Specialized in the production of refrigerator condenser and evaporator in 1984 . We have about 30 years experience in development and practical experience.  |
Technology:  | It owns over 50 sets of equipment imported from Italy and Switzerland and more than 10 sets of specialized testing and detecting equipment.  |
OEM:  | operate with Aucma, Little Swan, Midea, LG, TCL and other well-know domestic and foreign enterprises.  |
Advantages:  | Freon-free, high efficiency and energy saving.  |









CANTACT:
TEL:+86-716-8390039
MOB:+86-15927721264
SKYPE:Joany1991
WEB:http://jztaijia.en.china.cn/
Samples and drawings are welcome!
.
Company Profile
                    Jingzhou Taijia Refrigeration Equipment Co., Ltd. is a manufacturer established in 1984 and specialized in the research, development and production of wire tube condenser, wire tube evaporator, finned evaporator ,finned condenser and tube plate evaporator for refrigerator,freezer . We are located in Jingzhou, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
