Hot Sell Triple Layer Cable Wire Mica Taping Machine for Cable Shielding

JCJX- Hot Sell Triple Layer Cable Wire Mica Taping Machine

1, Our product

2,Main Specification

1. Lay range 10mm-50mm

2. Overlap 20%-50%

3. Line speed 35m/min max.

4. Speed of taping head: 2500rpm

5. Detail of motor: capstan 2HP, take-up 5HP, three taping head 3HP(each 1HP), motor and drive to be Siemens as your requirements.

6. Take-up bobbin din: active power take- up, flange 560 mm, traverse 335 mm,bore 127 mm, overall Width 375 mm, barrel Dia. 280 mm

7. Pay-off : single head tension type, bobbin din 560/630mm.

8. No. Of taping heads: 3

9.In the control panel:digital length counter preset, rpm meter and hour meter to be provided

10. Safe guards also to be provided

11. Detectors of tape brake to be provided

12. Drain wire bobbin din 200mm

13. Core gide paths to be provided with India anodic treatment rollers so that core movement

in the machine should not get damaged.

14. Tape pad size dia. 300mm,ID 75mm

15. Traverse plain shaft dia. 30mm

16. Lay changing: equip 3 sets stepless speed variator for 3 taping head, lay can be changed

through different speed.

17. Overlap is decided by the lay you set.

18. Tape tension: each tape head equiped with one electromagnetic powder tension linear track

2-1 usage

copper wire or cable surface's taping, for example: copper tape, mica tape, aluminum foil, polyester tape, transparent tape, mylar tape and non-woven, etc.

3,our cetificate

 4, our office ,factory and our team

we have 9 stroies building offive and mutilpul workshops and eight morden manufaturing plant.

5. After-sell service

5-1. Pre-sale training:

In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:

(1) Correct operating mode

(2) Correct maintenance way

(3) Remove simple proble

52. Guarantees

Since the shipment date, 12 month for mechanical part, and 6 month for electrical parts
