Intermediate Wire Drawing Machine Lines
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Jiacheng | |
| Model Number | JCJX-17DT | Usage | Drawing |
Product Description
JCJX-17DT Intermediate Wire Drawing Machine Lines
1. Usage:
This type is used for drawing and annealing copper wire from 2.5-3.2mm to 0.4mm-1.2mm.
2. Main Spec:
Machine type | JCJX-17DT |
Control system | PLC |
Inverter control | Dual inverter control |
Drawing dies No./max. | 17 |
Inlet diameter | Ø 2.5- 3.2mm |
Out diameter | Ø0.4- 1.2mm |
Drawing line speed /max | 1200m/min |
Slip ratio of m/c | 18% |
Fix speed capstan slip ratio | 15.5% |
Frame | Ironed cast |
Capstan | Carbon fibre plasma capstan |
Main motor | 37kw |
Spooler motor | 11kw |
Fix speed capstan dia. | Ø 250mm |
Dia.of annealing | Ø 250mm |
Annealing voltage | DC 0-60V |
Annealing current | DC 1500A |
Protection type | Steam or nitrogen |
Spool bobbin size | Ø 500mm or according to customers |
Optional take-up machine | Coiler |
3. Main Scope of Supply
4. Advantage:
1). JIACHENG is using only helical precision gear.
2). Special lubrication system for the gears and bearings
3) .Special seal system between the gear and drawing section.
3). Second-section-annealing system, outside electrically neutral (no current flow to other unit)
4). Machine’s body and other key components and parts are produced by our own factory, quality is reliable.
5.Packing
6. After-sell service
6-1. Pre-sale training:
In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
6-2. Guarantees
Since the shipment date, 12 month for mechanical part, and 6 month for electrical part.
