1000 w Fiber Laser Metal Cutting Machine 1500*3000

wooden case package

Specifications

1000 w fiber laser metal cutting machine 1500*3000

The application of laser cutting technology is a great processing for metal cutting industry. Laser with high accuracy, fast speed, small heat affected area, low use-cost, less maintenance cost, wide material adaptability and other outstanding advantages, is recognized as an alternative to traditional metal cutting. Compared to CNC punching machine, laser cutting machine no need mold and can cut complex graphics easily, no need secondary processing and higher cutting quality.
 GOLDEN LASER - Metal Laser Cutting Machine

Fiber Laser Cutting Machine 500W 1KW 2KW 3KW | YAG Laser Cutting Machine 500W 650W 800W

Working size: 600*400mm | 1300*900mm | 1300*2500mm | 1500*3000mm | 1500*4000mm | 2000*4000mm | 2000*6000mm
 Laser Cutting Machine Demo Videos on YouTube

© 1000W Fiber Laser Cutting Machine:            http://youtu.be/pTS88Tc77yI

© 2000W Fiber Laser Cutting Machine:            http://youtu.be/NA-O2Pfz3Ew

© 500W Fiber Metal Laser Cutting Machine:     http://youtu.be/_cfJX9hpj1w

© 650W 800W YAG Laser Cutting Machine:     http://youtu.be/PlF_oXvbu4s

© YAG Laser Cutting Machine for Metal Sheet and Tube:          http://youtu.be/1DzK5JBSEik

© CO2 Laser Cutting Machine for Acrylic, Wood, Steel Sheet:   http://youtu.be/o_Ao9uUkPsU

 Fiber Laser Cutting Advantage

(1) The fiber laser cutting series are metal precise processing equipment powered by fiber laser technology. The quality fiber laser beam results in faster cutting speeds and higher quality cuts compared to other cutting solutions. The key advantage of a fiber laser is its short beam wavelength (1,064nm). The wavelength, which is ten times lower than that of a conventional C02 laser, generates high absorption into metals. This makes the fiber laser become a perfect tool for cutting sheets of stainless steel, mild steel, aluminum, brass, etc.

(2) The efficiency of a fiber laser far exceeds traditional YAG or CO2 laser. The fiber laser beam is capable of cutting reflective metals with much less energy as the laser is absorbed into the metal being cut. The unit will consume little to no energy when not active.

(3) Another advantage of fiber laser is the use of highly reliable single emitter diodes with projected lifetimes greater than 100,000 hours of continuous or pulsed operation.

(4) Golden Laser software allows for the capability to control power, modulation rate, pulse width and pulse shape giving the user full control of the lasers capabilities.

 Fiber Laser Cutting - High efficiency & High quality cutting system - Fast and precision metal cutting solution

    •Long life time (100,000 hours) of the laser module (laser source 300W, 500W, 1000W, 2000W, 3000W)
    •Specially for high precision metal cutting
    •Small heat affected zones for narrow cutting “kerf”, have the ability to cut most complex design and sharp corner.
    • Auto focus system to change focus length automatically while process uneven materials
    •Nesting Software provides efficiency and saving materials
    •Minimized burrs and roughness
    •Lowest maintenance cost and energy-consumption
    •Easy operation

XJG-150300JH Fiber Laser Cutting Machine

 Fiber Laser Cutting Machine Features

1. Double ball screw close-loop system and open-type CNC system, ensure high processing accuracy and high working efficiency during high speed cutting.

2. Standard collocation of 2000W fiber laser generator and optional 500W~3000W fiber laser generator. Low maintenance cost.

3. Enclosure design conforms to CE standard for reliable and safe processing. Pallet changer working table is convenient for material uploading and unloading and further promotes working efficiency.

4. Aiming at high speed cutting, we design and manufacture strengthened welded machine body after 2 times of aging process, ensuring long-term accuracy and stability of performance.

5. Standard collocation of dual-pressure gas control system of 3 gas sources (high pressure air, nitrogen, oxygen) meets the processing requirement of all kinds of materials. Easy operation and low cost.

6. Standard collocation of automatic nesting software (including material management and optimized processing technology) and providing with database of process parameters for easy operation and simple management.

7. Optimized optical lens, specially designed nozzle and sensor technology realize more smooth and more stable cutting. Optional collocation of 2000mm×4000mm, 2000mm×6000mm working table.

 Laser Cutting Metal Application Field

laser cutting machine suitable for cutting stainless steel, carbon steel, mild steel, alloy steel, galvanized steel, silicon steel, spring steel, titanium sheet, iron sheet, inox sheet and other metal sheet, metal plate, etc.

laser cutting machine applicable to sheet metals, electrical cabinet, kitchenware, hardware, metal enclosure, advertising, lighting lamps, decoration, medical instruments, automotive parts and other metal cutting fields.
 Laser Cutting Machine Technical Parameters

 Fiber Laser Cutting Industry

 Laser Cutting Metal Samples

Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
For the big machine, we will order the special container to load

Golden Laser - Golden Service
Installation Service
Installation Services are available with all GOLDEN LASER machines. We will dispatch technician to The Buyer's factory for installation and preoperation of machines.
Training Service
Our technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines.
Quality Guarantee
We guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data.
We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make delivery.
Machine warranty is 1 year. We offer flexible extended warranties to our clients if needed.
Laser machines purchased from Golden Laser installation and maintenance, we provide “1+6” complete services.
Standardization of Service “212"
2: response in 2 hours
1: provide solution in 1 day
2: solve complaint in 2 days
"1+6” Complete Services Specification
One Installation Service “one-time" OK
Six Complete Services
1. Machinery and circuit check
Explain the functions of machine parts and ensure machine’s long-term operation.
2. Operating guide
Explain the use of machines and software. Guide the customer proper use, extend product life and reduce energy consumption.
3. Machine maintenance
Explain the maintenance of machine parts to extend product life and save the energy consumption
4. Product Process guide
Depending on different materials, do testing to get optimal processing parameters to ensure the best quality of products.
5. Site clean-up services
Clean the customer site when service is completed.
6. Customer evaluation
Customers give the relevant comments and rating about service and installation personnel.

 Why Golden Laser

© Laser innovative application service platform

© Leading laser solution provider

© More than 12 years experience in laser industry

© Laser-World of Photonics Exhibitor since 2005

© Strict quality control and exclusive after-sales service team

© Providing customized laser machines for users and distributors globally

Welcome to contact Golden Laser by leaving a message below for more information. Your kindly reply of following questions will help us to recommend the most suitable machine for you as soon as possible.

   1, are you interested in laser cutting machine?  what material do you need to cut?

   2, what working size do you need?

   3. what is the thickness of the material? (what is the mostly used thickness and what is the maximum thickness?)

   4, after cut, what will be the material used for? (application)

   5, are you an end user or reseller?

    E.M.A.I.L:           info(at)

    Site:

    YOUTUBE:       /user/Goldenlaservideo

 Fiber Laser Metal Cutting Machine | Looking for users and distributors globally.
