AV/SV to HDMI 4Kx2K Scaler Converter Box

Introduction

The AV/SV to HDMI 4Kx2K Scaler Converter is a universal converter for analog composite input to HDMI 4Kx2K@60Hz output. The analog to digital conversion in this module employs 10 bits maximal 297MSPS sampling, black/white level expansion, color transition improvement, dynamic range expansion, blue stretch , auto-detect and auto-convert the composite signal to HDMI output. Making video come alive, delivering the sharpest, most realistic HD visuals available.

Features

1. 1.           No need to install drivers, portable, flexible, plug and play.
2. 2.           Provide advanced signal processing with great precision, colors, resolutions, and details.
3. 3.           Support PAL,NTSC3.58,NTSC4.43,SECAM,PAL/M,PAL/N standard TV formats input.
4. 4.           Support HDMI 4Kx2K@60Hz, 4Kx2K@30Hz,1080p@60Hz or 720p@60Hz output.

Specification

Input ports: 1xRCA (Yellow, White, Red). 1x S-Video, 1 x Min- USB

Output ports: 1xHDMI

Dimensions(mm):   93(D)x84(W)x28(H)

Wight (g):          165g

CVBS/S-VIDEO input:   PAL,NTSC3.58,NTSC4.43,SECAM,PAL/M,PAL/N standard TV formats

HDMI output resolution:   4Kx2K@60Hz,4Kx2K@30Hz,1080P@60Hz,720P@60Hz

Operating Temperature                     0°C ~ 40°C / 32°F ~ 104°F

Storage Temperature            -20°C ~ 60°C / -4°F ~ 140°F

Elative Humidity              20 ~ 90% RH (Non-condensing)

Power Consumption (Max)     3.5W

ESD Protection                        Human Body Model:

± 8kV (air-gap discharge)

± 4kV (contact discharge)

Package

1. 1.   AV/SV to HDMI 4Kx2K Scaler Converter                                 1 pcs
2. 2.   5V1A DC Power Supply Adaptor                                  1 pcs
3. 3.   Operation Manual                                                   1 pcs
