Home > Products > New Products > Semi-automatic Can Body Blanking Punch Pressing Machine For Round Popcorn Tin Can Bucket Making Line
Semi-automatic Can Body Blanking Punch Pressing Machine For Round Popcorn Tin Can Bucket Making Line
- Ningbo
- T/T L/C D/P D/A Credit Card
You May Like
-
Manual/Semi-automatic Tin Can Roll Forming Maker For Beer Ice Bucket Promotion Barware Wine Cooler Tin Bucket Production Line
-
Manual/Semi-automatic Tin Can Roll Forming Maker For Round Popcorn Can Bucket Production Line
-
Semi-automatic Tin Can Seam Lock Welding Machine For Make Colorful Popcorn Tin Can Bucket Producton Line
-
Semi-automatic Tin Can Seam Lock Welding Machine For Beer Tin Can Bucket Producton Line
-
Semi-automatic Tin Can Bottom Sealing Machine Of Popcorn Tin Can Production Line
-
Semi-automatic Tin Can Seamer Sealing Machine For Round Popcorn Can Bucket Production Line
Product Details
| Condition | New | Application | Beverage, Chemical, Food, Other, Beverage, Chemical, Food, Machinery & Hardware | |
| Packaging Type | Cans | Packaging Material | Metal | |
| Automatic Grade | Semi-Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 7.5KW | |
| Place of Origin | Zhejiang, China | Brand Name | Golden Wing | |
| Model Number | J23-80 | Dimension(L*W*H) | 1990*1410*2945 | |
| Weight | 5970KG | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
| Name | J23-80 Punch Press |
| Usage | It's used for can body blanking |
| Nominal force | 800kn |
| Stroke under nominal force6 | 9mm |
| Slide block stroke55 | 130mm |
| Number of stroke80 | 45mm |
| Max die set height | 290 |
| Die set height adjustment | 100mm |
| Distance from slide block center to the frame | 300mm |
| Worktable dimension | Φ580*860mm |
| Dimension of worktable hole | Φ200*45*Φ180mm |
| Thickness of bolster | 100mm |
| Hole dimensions in bed | Φ280*220*380mm |
| Dimensions of side block bottom surface | 280*380mm |
| Size of the handle hole | Φ60*75mm |
| Max. tilting angle of body | 20° |
| Distance between columns of body | 410mm |
| Motor power | 7.5kw |
| Outline dimension | 1990*1410*2945mm |
| Net weight | 5970kg |
Zhoushan Golden Wing Machinery Co.,Ltd, is a professional exporter specialized in various tin cans making
machinery.
As a rich experienced exporter in tin can making machines, we always make the most suitable solutions for
customers in tin cans making.
High quality, competitive price and superior after-sale service are our principle.
We are always ready to develop long-term and good relationship with overseas customers.
We provide the following series of products:
Automatic Food Tin Can Production Lines
Automatic Beverage Tin Can Production Lines
Automatic Chemical Tin Can Production Lines
Automatic Aerosol Tin Can Production Lines
Automatic Tin Ends Production Lines
Automatic EOE Production Lines
Semi-automatic 1-5L Round/Square/Rectangular Tin Can Production Lines
Semi-automatic 10-25L Paint Can Production Lines
Semi-automatic 18L Square Tin Can Production Lines
Semi-automatic 50L Tin Pail Production Lines
Punching Dies
And so on.......
'To be the best supplier' is the attitude of our company. We will keep on providing modern and advanced
machines to bring greater value-added benefit for our customers.
If you want to know more about our machinery, please don't hesitate to contact us at any time.
Welcome to our company!
