Automatic roll forming seam welding coating drying machine for chemical metal bucket making production line
- 10 Set / Sets per Month
- Ningbo/Shanghai
- T/T
You May Like
-
Automatic High Stability Chemical Tin Can Manufacturing Machine
-
Automatic Bucket Container Tin Can Box Seamer Machine
-
Automatic Tomato Paste Ketchup Tin Can Box Seam Welding Machine Welder
-
Roller Coating and Induction Drying Series for tin can making line
-
Automatic Labelling machine for round tin can
-
Soft Drink Beverage Can Filling & Seaming Closing Machine
Product Details
| Condition | New | Application | Beverage, Chemical, Food, Other, Beverage, Chemical, Food, Machinery & Hardware | |
| Packaging Type | Cans | Packaging Material | Metal | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380v | Place of Origin | Zhejiang, China | |
| Brand Name | Golden Wing | Dimension(L*W*H) | 1730*1695*1920mm+ 2100*820*1800mm +8500*800*1550mm | |
| Weight | 4600KG | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
| Name | Automated Chemical Metal Bucket Producing Line |
| Usage | It's used for can body roll forming, seam welding, coating and drying. |
| Welding Speed | 6-24m/min |
| Capacity | 30-100 cans/min |
| Can Diameter | Φ90-180mm |
| Can Height | 70-330mm |
| Welding point distance | 0.5-0.9mm |
| Overlap | 0.4-0.6mm |
| Sheet Thickness | 0.16-0.30mm |
| Can Material | Tinplate |
| Tinplate Hardness | T2 - DR8 |
| Copper Wire Diameter | Φ1.38mm |
| Compressed Air | 0.5Mpa, 800L/min |
| Cooling Water | 0.4Mpa,12-18°C, 20L/min |
| Coating Speed | 6-30m/min (roller coating, automatic glue-feeding) |
| Coating Width | 10-14mm |
| Drying Speed | 12-30m/min (high frequency induction drying) |
| Welding Machine Dimension | 1730*1695*1920mm |
| Coating Machine Dimension | 2100*820*1800mm |
| Drying Machine Dimension | 8500*800*1550mm |
| Input Power | 3-phase, AC380V, 50Hz, 80KW |
| Total Weight | 4600kg |
Zhoushan Golden Wing Machinery Co.,Ltd., is a professional manufacturer & exporter specialized in various tin cans making machinery.
As a rich experienced manufacturer & exporter in this field, we always make the most suitable solutions for customers in tin cans / ends making.
‘High quality, competitive price & superior after-sale service’ is our principle.
We are always ready to develop long-term and good relationship with overseas customers.
