Home > Products > Iron worker > metal ironworker or hydraulic ironworker Q35Y-16Ton
metal ironworker or hydraulic ironworker Q35Y-16Ton
- 80 Set / Sets per Month
- Shanghai
- T/T D/P D/A
You May Like
Product Details
| Condition | New | CNC or Not | Normal | |
| Power Source | Hydraulic | Place of Origin | Shanghai, China | |
| Brand Name | hvcen | Model Number | Q35Y-25 | |
| Voltage | 380 | Power(W) | 7.5 | |
| Weight | 4800 | Dimension(L*W*H) | 2355*960*2090 | |
| Certification | CE ISO | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
metal ironworker,hydraulic ironworker
First:FEATURE OF Q35Y-25 Hydraulic Ironworker Tools
1.Double cylinders hydraulic punch & shear machine
2.Five independent stations for punch, shear, notcher, section cut
3.Large punch table with multi-purpose bolster
4.Removable table block for overhang channel / joist flange punching applications
5.Universal die bolster, easy change punch holder fitted, punch adapters supplied
6.Angle, round & square solid mono block crop station
7.Rear notching station, Low power inching and adjustable stroke at punch station
8.Centralized pressure lubrication system
9.Electric panel with overload protection elements and integrated controls
10.Safety movable foot pedal
11. Function: Punching, Angle Steel Shearing, Flat Bar Shearing, Round/Square Bar Shearing, Notching, V-Notching, C-Channel Shearing, I-beam shearing, T-bar shearing, Press Brake, Angle Bending and Pipe Notching.
Second :Technical data
NO. | ITEMS | PARAMETER | UNITS |
1 | Model | Q35Y-25 | 1 |
2 | punching pressure | 110 | T |
3 | max.cutting thickness of steel plates | 25 | mm |
4 | plate strength | ≤450 | N/mm² |
5 | angle of shear | 8° | ° |
6 | A trip size(TxW) | 25*330 | mm |
7 | Slider trip | 80 | mm |
8 | trip frequency | 8-25 | Times/min |
9 | throat depth | 400 | mm |
10 | punch depth | 25 | mm |
11 | Max.punching diameter | 35 | mm |
12 | Power | 7.5 | KW |
13 | Overall dimension(LxWxH) | 2355*960*2090 | mm |
14 | Weight | 4800 | kg |
