q35y-20 hydraulic ironworker/steel punch
- 80 Set / Sets per Month
- Shanghai
- T/T D/P D/A Credit Card
You May Like
-
q35y punching and shearing machine/ficep ironworker
-
Q35Y Series hydraulic combined punching machine/iron worker machine
-
hydraulic combination of punching and shearing/iron worker
-
machines ironworks production/hydraulic cylinder
-
Q35Y hydraulic channel cutting machine/used folding tables
-
q35y-25 hydraulic cutting machine price/combination machines
Product Details
| Condition | New | CNC or Not | Normal | |
| Power Source | Hydraulic | Place of Origin | Shanghai, China | |
| Brand Name | hvcen | Model Number | Q35Y-20 | |
| Voltage | 380 | Power(W) | 5.5 | |
| Weight | 2300 | Dimension(L*W*H) | 1640*800*1900 | |
| Certification | CE ISO | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
q35y-20 hydraulic ironworker/steel punch
First:FEATURE OF Q35Y-20 Hydraulic Ironworker Tools
1.Double cylinders hydraulic punch & shear machine
2.Five independent stations for punch, shear, notcher, section cut
3.Large punch table with multi-purpose bolster
4.Removable table block for overhang channel / joist flange punching applications
5.Universal die bolster, easy change punch holder fitted, punch adapters supplied
6.Angle, round & square solid mono block crop station
7.Rear notching station, Low power inching and adjustable stroke at punch station
8.Centralized pressure lubrication system
9.Electric panel with overload protection elements and integrated controls
10.Safety movable foot pedal
11. Function: Punching, Angle Steel Shearing, Flat Bar Shearing, Round/Square Bar Shearing, Notching, V-Notching, C-Channel Shearing, I-beam shearing, T-bar shearing, Press Brake, Angle Bending and Pipe Notching.
Second :Technical data
NO. | ITEMS | PARAMETER | UNITS |
1 | Model | Q35Y-20 | 1 |
2 | punching pressure | 80 | T |
3 | max.cutting thickness of steel plates | 20 | mm |
4 | plate strength | ≤450 | N/mm² |
5 | angle of shear | 8° | ° |
6 | A trip size(TxW) | 20*330 | mm |
7 | Slider trip | 80 | mm |
8 | trip frequency | 8-25 | Times/min |
9 | throat depth | 355 | mm |
10 | punch depth | 20 | mm |
11 | Max.punching diameter | 30 | mm |
12 | Power | 5.5 | KW |
13 | Overall dimension(LxWxH) | 1640*800*1900 | mm |
14 | Weight | 2300 | kg |
