Home > Products > disc harrow > 1BQDX Opposed Light-duty Disc Harrow
1BQDX Opposed Light-duty Disc Harrow
- QINGDAO
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Farm Cultivator | |
| Power Type | Other, tractor | Power(W) | 35-100 | |
| Certification | CE | Warranty | one year | |
| Use | tillage | Place of Origin | Shandong, China | |
| Brand Name | yunhai | Model Number | 1BQDX | |
| Weight | 330-650 |
Iron frame
Product Description
Specifications
opposed light-duty harrow:1: working width:1200-5000mm
2:working depth:100-400mm
3: linkage: three point mounted
opposed light-duty harrow:
1BQDX series opposed light harrow : This series are used for crushing clods after tillage, preparing
soil before seeding , loosening the soil , combining the soil and fertilizer , and cleaning away stubble
of plants in light soil field . With reasonable structure, strong ability to rake , durable, easy to use and
maintenance, etc.
item | unit | 1BQDX-1.25 | 1BQDX-1.6 | 1BQDX-2.0 | 1BQDX-2.3 | 1BQDX-2.65 | 1BQDX-3.0 | 1BQDX-5.0 | |
working width | mm | 1250 | 1600 | 2000 | 2300 | 2650 | 3000 | 5000 | |
working depth | mm | 100-140 | |||||||
No. of disc | pc | 16 | 20 | 24 | 28 | 32 | 36 | 60 | |
Dia. Of disc | mm | 460 | |||||||
inch | 18” | ||||||||
weight | kg | 330 | 390 | 460 | 560 | 600 | 650 | 1550 | |
linkage |
| Three point mounted | Trailed | ||||||
Matched power | hp | 35-40 | 40-45 | 50-60 | 60-75 | 75-85 | 80-100 | ||
Company Profile
Yucheng Yijia Machinery Co., Ltd. is a specialized manufacturer dealing with the design and production of agricultural machinery. We are a key company designated by the Ministry of Machinery Industry to produce hitching disc harrow, disc plough, blade, break shovel, and broadcast sowing machinery. Our products are exported to the United States, Australia, France, Germany, Russia, Pakistan, Thailand, Africa and South America, more than 20 countries and regions. Our factory was promoted to be entitled as National 2nd-class Enterprise and got independent export rights. We own rich technical force, advanced equipment, excellent workshop and high prestige, and can supply consumers with reliable products and satisfactory service. Our certificates and titles 1. A Class Enterprise of the National 2. Agricultural Machinery Spread License issued by the Ministry of Farming, Animal Husbandry and fishery of China 3. Production License of the whole National. 4. Certificate of Measuring and Inspection by National Technical Control Bureau
Contact Us
- Yucheng Yijia Machinery Co., Ltd.
- Contact nameFrank Dong Chat Now
- Phone0086-534-7321259,7327280,73618
- AddressEast End Of North Ring Road, Hi-Tech Development Zone
