Home > Products > high voltage multipliers > high voltage module
high voltage module
Negotiable
/ Pack
10 Packs(Min.Order)
- 100 Piece / Pieces per Month
- Dalian
- Credit Card
You May Like
-
voltage multiplier assembly
-
LS60KV-250mA Latest Style High Quality electrostatic power supply
-
LS60KV-250mA Latest Style High Quality industrial power supply
-
LS60KV-250mA Specialized suppliers high voltage regulator power supply
-
LS60KV-250mA Best quality new design security power supply
-
LS60KV-250mA China Wholesale Custom universal power supply
Product Details
| Model Number | MV | Brand Name | Leadsun | |
| Place of Origin | Liaoning, China |
Product Description
Specifications
AC inputting can over 20KV.Ultra fast recovery HV diode
working frequency can reach 200KHZ.
DC output can reach 400KV.
Type | Multiplications (N) | Max input voltage (KV) | Output voltage (KV) | Max output current (mA) | Max working frequency (KHZ) | Outline dimension L*B*H mm | Mode of output |
MV24-AC12V-80KV/0.1mA | 24 | 12V AC | 80 | 0.1 | 40 | HV cable | |
MV08-10KV-80KV/0.5mA | 8 | 10 | 80 | 0.5 | 40 | 240*70*70 | HV terminal |
MV10-10KV-100KV/0.5mA | 10 | 10 | 100 | 0.5 | 40 | 260*70*70 | HV terminal |
MV08-6.5KV-50KV/1mA | 8 | 6.5 | 50 | 1 | 50 | Customize | HV terminal |
MV16-6.5KV-100KV/1mA | 16 | 6.5 | 100 | 1 | 50 | Customize | HV terminal |
MV08-6.5KV-50KV/5mA | 8 | 6.5 | 50 | 5 | 50 | Customize | HV terminal |
MV16-6.5KV-100KV/5mA | 16 | 6.5 | 100 | 5 | 50 | Customize | HV terminal |
MV08-6.5KV-50KV/10mA | 8 | 6.5 | 50 | 10 | 50 | Customize | HV terminal |
MV16-6.5KV-100KV/10mA | 16 | 6.5 | 100 | 10 | 50 | Customize | HV terminal |
MV06-8.5KV-50KV/20mA | 6 | 8.5 | 50 | 20 | 50 | Customize | HV terminal |
MV12-8.5KV-100KV/20mA | 12 | 8.5 | 100 | 20 | 50 | Customize | HV terminal |
