22.5 Degree Pipe Elbow
- Shanghai ; Ningbo;Any China Port As Customer Requirest
- T/T
You May Like
Product Details
| Material | Other, carbon steel ,alloy steel, stainless steel | Technics | Forged | |
| Type | Elbow | Model Number | elbow | |
| Brand Name | Jetsun | Connection | Other, Welding, welding,threaded connection , socket weld joint | |
| Shape | Equal | Head Code | Other, Round |
Product Description
22.5 degree pipe elbow
♦Product specification
Name: | 22.5 degree pipe elbow | |
Material: | Carbon Steel: | 1.ASTM A-234 (WPB,WPC) 2.EN 10216-2(P235GH,P265GH) 3.EN10222-2(P245GH,P280GH) |
Low Alloy Steel: | 1.ASTM A-420(WPL6) | |
Stainless Steel: | 1.ASTMA403M (WP304,WP304L,WP304H,WP316,WP316L,WP321,WP321H,WP347) 2.EN10216-5(X2CrNiN18-10(1.4311) 3.X5CrNi18-10(1.4301) 4.X5CrNiMo17-122(1.4401) 5.X2CrNiMo17-12-2(1.4404) | |
Standard: | ASTM, ASME,DIN,JIS,API,GB,ISO | |
Certifications: | ABS,CC,TUV,GL ,BV,ISO14001,ISO9001,OHSMS | |
Connection type: | BW,SW,THD. | |
Surface treatment: | Anti-corrosion, galvanized… | |
Size: | (1/2″~92″) DN15~DN2400 | |
Customizes Size: | Non-standard size can be customized as per customer’s request. | |
Wall thickness: | SCH5S~SCH160 STD XS XXS | |
Testing: | Chemical Component Analysis, Mechanical Properties(Ultimate tensile strength, Yield strength, Elongation),Technical,Properties(Flattening Test, Bending Test, Blow Test, Impact Test),Exterior Size Inspection, Hydrostatic Test, X-ray test. | |
Testing Report: | SGS,BV etc. 3rd Party Testing Report is available. | |
♦Picture show
♦Product size
Remarks :
1) Normal size above are provided for you reference .
2) Custom made as customers' requirements for special Size .
♦Product certifications
1) Packing Method:
Normal packing:plastic film or bubble paper wrapped on product's surface ,protect ends with caps,pack with wooden case or load on fumifation plywood pallet .
Custom made as customers request .
2) Shipping Way:
Usually by Sea, By Air, By Train or River-and-Sea Coordinated Transport.
As per customer's request.
♦What can I do for you?
A. Stable quality—with advanced equipments and all raw materials comes from stat-owned mill in China.
B. Competitive price—Not cheapest but the lowest at the same quality.
C. Good service—one-stop service, we can supply the steel pipe and pipe fittings for oil and gas industry.
D. Delivery time—on-time delivery, lots of stock for standard size pipes.
E. Customized ,small/trail order and mixed order are welcomed.
♦Inquiry note
For your convenience and save your time,to quote you with best price,please read the inquiry note and tell us the details as follow.
Why choose us?
History
We,Jetsun was established in 2002 , we have 13 years experience in field of steel tube and pipe fittings, we are a professional supplier of steel products in China.
Trade Partners
We have established the good business relationship with many famous domestic manufacturers and also supply the products to numbers of well-known international company.
All products are well-reputed by customers from all over the world, for example, our company has been qualified to be a key supplier by Singapore Keppel Corporation which is one of largest state-owned enterprise in Singapore.
Enthusiastic Team
We are big family with strong teamwork spirit.We believe profession makes perfect..
