Super-Slim splicing LCD wall/Splicing screen/Utra narrow LCD sreen

FOB Price

Negotiable / Set

5 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Prapad
Model Number	ETP-46M-UN		Type	COB

Splicing LCD wall
Super narrow gap,edge join:5.3mm
DID industrial-grade LCD screen.

Splicing LCD wall

Feature

1,Super narrow gap,edge joint is 5.3mm

2,DID industrial-grade LCD screen.

3,Brightness:700CD/M*2

4,The shell of splicing screen is cold-rolled steel.

5,The color of saturation can achieve to 97%.

Parameter

Model	ETP-46M-UN	ETP-47M-UN	ETP-55M-UN	ETP-60-UN
Size	46 inches	47 inches	55 inches	60 inches
Appreance size	1025.6580105mm	1046.8591.693.5mm	1215.4686.1122mm	1322.3745.771mm
Display Area	1018.9*573.3mm	1039.87*584.64mm	1209.9*680.6mm	1318.6*741.9mm
Resolution Ratio	1366*768P	1920*1080P		1365*768P
Maximum power	250W	250W	350W	500W
Rated power	180W	180W	280W	420W
Bilateral splicing seam	6.7mm	6.7mm	5.3mm	6.3mm
Total weight	24.7KG	25.4KG	34.6KG	26.3KG
Brightness	700CD/m*2
Constract	3000:1
Response time	8ms
Visual angle	178°
Line frequency	65-70Hz
Field frequency	60Hz
color system	PAL/NTSC
Input/Output	1Vp-p,75Ω,BNC*2
DHMI/DVI/VGA input	*1
Communication interface	RS232 loops input/output
Power	AC110V-240V,50/60Hz
Temperature	0°C~60°C
Humidity	10%~90%
Operation	PC control software for the big screen
Cooling	Intelligent temperature control cooling system
case material	SPCC
Installation	cabinet type/floor-type/wall-mounted

Applcation

Certification

Factory information
