Small Tractor Towable 3PT Hydraulic Backhoe LW-6, LW-7, LW-8

FOB Price

US$ 1,800 - 2,200 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Farm Machinery
Place of Origin	Shandong, China	Brand Name	LUWEI
Model Number	LW-6/LW-7/LW-8	Dimension(LWH)	22008501100mm
Weight	500KG	Features	Tractor Backhoe
Certification	ISO9001	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

Specifications for tractor towable backhoe LW-6,LW-7

Model		LW-6		LW-7
Specification		Inch	Metric	Inch	Metric
Tractor HP		25-30HP		30-45HP
3-point Linkage		Cat-1		Cat-1
Structure Weight		1060lb	480kg	1100lb	500kg
A	Digging Depth(two foot flat bottom)	5.74’	1750mm	6.4’	1950mm
B	Reach from center line of Swing pivot	8.53'	2600mm	9.51’	2900mm
C	Loading Height(bucket at 60°)	5.64’	1720mm	6.03’	1840mm
D	Transport Height(maximum)	6.03’	1840mm	6.75’	2060mm
E	Extend Height	9.41'	2870mm	10.2'	3110mm
F	Loading Reach(bucket at 60°)	3.11’	950mm	3.87'	1180mm
G	Transport Overhang	3.54'	1080mm	3.64'	1110mm
H	Undercut	2.4'	730mm	2.72'	830mm
I	Bucket Rotation	180°		180°
J	Stabilizer Spread(up position)	4.3’	1310mm	4.3’	1310mm
K	Stabilizer Spread(down position)	4.3’	2100mm	6.9’	2100mm
L	Swing Arc	180°		180°
M	Bucket width	300mm		400mm
N	Bucket cubage	0.036		0.045

Tractor with Front End Loader and Backhoe

3Point Linkage Show:

Packaging and Shipping
