IP44 300x1200 touch panel led controller colorful 36w/48w/54w/72w

LED Light Source	Epistar		Warranty(Years)	3
Input Voltage(V)	100-240V		Lamp Power(W)	36
Lamp Luminous Flux(lm)	2350-2700Lm		Lamp Luminous Efficiency(lm/w)	75
Color Temperature(CCT)	Other, 2800-6500K		Working Temperature(℃)	-20, 60
Working Lifetime(Hour)	50000		Lamp Body Material	Aluminum Alloy
IP Rating	IP44		Certification	CE, FCC
Place of Origin	Guangdong, China		Brand Name	Chigather
Model Number	C-30120H9

Specifications

touch panel led controller
1.LED panel light size:300*1200*9mm
2.Input:100-240V
3.LED Type:SMD3014,SMD2835
4.CE,FCC,ROHS

IP44 300x1200 touch panel led controller colorful 36w/48w/54w/72w





LED panel light feature and benefits:

-Green lighting without pollution: powered with direct current and with lower power consumption. Save up to 80% compared to traditional lighting.

-Safe: NO UV or no infrared radiation, no mercury or lead, it can be touched safely.

-Long-lasting: a lifespan of more than 50,000 hours.

-Ultra thin and ultra light, its LED color can be customized by the end user.

-Striking: LED lighting is colorful, and the white color temperature can be made from 2800K to 7500K.

-Built-in high efficiency constant current driver, Wide Voltage AC100-240V 50/60Hz input, worldwide application.



LED panel light 300*1200*9mm specification:

LED PANEL LIGHT 300*1200*9mm
MODEL	SIZE(mm)	POWER	INPUT	SMD2835	SMD3014	FLUX	Fixing Way	Packing
C-30120H9	300*1200*9	36W	100-240V	180 PCS	320 PCS	2350-2700Lm	N-built Mounting Suspending Jump ring Reverse Buckling	Inner Box:1277*340*40         Outer Carton:1297*360*185(4pcs)                       Weight/CARTON:17.38 (4pcs)
		48W		240 PCS	456 PCS	3100-3600Lm
		54W		280 PCS	480 PCS	3500-4100Lm
		72W		360 PCS	640 PCS	4700-5400Lm





Functional LED panel light

LED PANEL LIGHT with controller

Controller for color temperature dimmable

RGB for brightness dimmable

24 keys infrared RGB controller

Silicon dimmable controller

Sound and light switch

Infrared PIR switch



LED panel light Packing Information:





LED panel light Fixing Way:





LED panel light application:

LED panel lights are used in corridors, houses, conferences/meeting rooms, hotels, factories, and more.

Specially in shopping malls, parking lots, hospitals, schools, as well as eye-care illumination for students.
