JY--201B AUTOMATIC Stretching Film Wrapping Machine

Wrapping Machinery Standard Features:

 turntable diameter: 1650mm, 1800mm, 2000mm
 wrapping height: 2100mm
•Spring break stretch
•Home position: the turntable always stops at the same position
•Speed control on turntable
•Choose between 1 & 9 top and bottom wraps with re-enforce wrap
•Up & down or up only wrap cycle
•Semi auto and manual wrap options
•Adjustable pallet height photo sensor
•Secure Top Sheet Function
•Lockable control panel
•Adjustable tension with quick release
•Soft start and stop
•Machine can be paused during cycle
•Magnetic brake holds turntable still during loading/unloading
•Audible warning when running a cycle

Wrapping Machinery Specification:

•Max. wrapping height:2000mm
•Max. turntable speed:12rpm/min

•Max.efficiency:25loads/hour
•Max. loading weight:2000kgs

•1650mm turntable diameter(standard machine)
•Film roll width:500mm
•Film roll outer diameter:250mm
•Film roll inner diameter:76mm

•Machine size:L2545mm*W1650mm*H2280mm

•Machine weight:650kgs
•Power supply:110-220V 1phase 1.5 KW  50/60HZ

Wrapping Machinery Standard Options:

•Multi-positional ramp for hand pallet trucks (3000 kilos maximum load weight)
•Extra-long ramp for use with powered pallet trucks
•Pit Frame
•1800mm-3000mmTurntable (Special Order)
•2200mm-3000mm Wrapping Height (Special Order)
•Horse Shoe Style Turntable (Special Order)

Wrapping Machinery Safety Features:

•conforms to current HSE legislations
•safety cut-out on film carriage and control panel
•height limitation sensors
•600mm gap between the edge of the turntable and the nearest fixed point
•Anti drop film carriage
•Audible warning when running a cycle
