Pinion and Rack Construction Hoist
Negotiable
/ Set
1 Set(Min. Order)
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | huiyou | Model Number | SC100/100 | |
| Rated Loading Capacity(kg) | 2*1000kg | Hoisting Speed | 34.4m/min | |
| Max Lifting Height | 150-200m | Dimension(L*W*H) | 3.0*1.3*2.3m | |
| Loder Weight | 2*1000kg | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Pinion and Rack Construction Hoist
Rated Load(kg) | 2*1000 |
Rtated Passengers | 2*10 |
Rated Lifting Speed(m/min) | 34.4 |
Motor Power(kw) | 2*2*15 |
motor Breaking Torque(N.M) | 120 |
Overrun Protection Device breaking Speed(m/min) | 51-56 |
Overrun Protection Device Rated Breaking Load(KN) | 30 |
Max.Lifting Height(m) | 150-200m |
Cage Size(L*W*H)(M) | 3.0*1.3*2.5 |
Mast Section Size(L*W*H)(M) | 0.65*0.65*1.508 |
Mast Weight(kg) | 158 |
Rated Erection Load(kg) | 200 |
