optic fiber FBT splitter/passive optical splitter

FOB Price

US$ 10 - 250 / Unit

50 Units(Min. Order)

Port shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China		Brand Name	W-TEL
Model Number	WTEL-TY6

Product Description

Specifications

passive optical splitter
comply with Telcordia GR-1209&GR-1221
ISO9001:2000
Excellent quality
Deutsche Telecom

passive optical splitter

The separation and the component of the optical signal are made by a fiber structure, used for the work of the system of communication and television by cable. It has good optical operation, quality and stability and is applicable to use in difficult conditions. In addition, there are several aspects to choose.

1.Tabla of the operation

model	normal	broadband	double
wavelength	1310o1550nm	1310o1550nm	1310o1550nm
bandwidth	±20nm	±40nm	±40nm
loss of accessories	≤0.10dB	≤0.15dB	≤0.15dB
uniformity	≤0.6dB	≤0.6dB	≤0.6dB
polarization	≤0.1dB	≤0.1dB	≤0.1dB
direction	55dB	55dB	55dB

2.Distribution of the splitter and extra loss:

N	extra loss (db)	N	extra loss (db)	N	extra loss (db)	N	extra loss (db)	N	extra loss (db)
3	0.3	4	0.4	5	0.45	6	0.5	7	0.55
8	0.6	9	0.7	10	0.8	11	0.9	12	1.0
16	1.2

3.Environmental

conditions
high temperature	85±2ordm; C, 2000 hours
Warm and Humidity	75±2ordm; C/90±5%RH, 2000 hours
low temperature	-40±5ordm; C, 2000horas
water immersion	43±2ordm; C/PH5.5±0.5, 168 hours
circulation of the temperature	-40±2ordm; C until 75±2ordm; C, 500 periods
vibration	10Hzhasta 2000Hz, amplitude 1.52mm, 3 directions, 4 hours/direction
impact	1.8m height, 3 directions, 8 times/direction
