Home > Products > Standard Springs > Easy to Use and Durable KSSC Super Spring Din Standard Compression Spring for Research

Easy to Use and Durable KSSC Super Spring Din Standard Compression Spring for Research

FOB Price

US$ 20 - 80 / Bag

1 Bag(Min. Order)

Port Tokyo Narita Yokohama
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Japan	Brand Name	KSSC Super Spring
Model Number	compression-002	Style	Coil
Load Type	Compression	Material	Stainless Steel
Usage	Other, Various purposes

Product Description

Easy to use and Durable KSSC Super Spring din standard compression spring for research

Offering an abundant lineup of standardized springs in small packages, starting from single bags.

Prompt delivery possible for all 2524 product types.

Reliable, high quality. Thorough quality control and support for all varieties of industrial goods.

Product Description

Super Spring is a standardized, made in Japan spring designed with all of the necessary features.but none of the complicated planning, for the purpose of simple acquisition of multiple types in small quantities.

We are able to cope with all design and technical needs, including prototypes,small batch manufacturing, maintenance, and repair.
We maintain a full inventory of our whole product line-up.

Products are delivered in a timely fashion.

The compression coil spring of the Super Spring series can be divided roughly into 3 series,

and be selected according to a necessary usage from among abundant lineups.

Super Spring series LINEUP

series

This standard regulates general use cylindrical cold formed helical compression spring that use circular cross-section materials ranging in diameter from 0.2–3.2 mm.

Compliant with Japan Spring Manufacturers.
Association standards (JSMA No. 7 “Helical cylindrical compression springs” ).

series

Helical cylindrical compression springs compliant with the German popular standard

DIN 2098.
This standard regulates general use cylindrical cold formed helical compression spring that use circular cross-section materials ranging in diameter from 0.1–10.0 mm.

Compliant with Japan Spring Manufacturers.

DS series

Springs with D Series standard dimensions made of stainless spring steel.

This standard regulates general use cylindrical cold formed helical compression spring that use circular cross-section materials ranging in diameter from 0.50–5.0 mm.

Compliant with Japan Spring Manufacturers.

Compression Springs - SPECIFICATION
Series Name	K series	D series	DS series
Product No.	1001 ~ 1230	5001 ~ 5850	8001 ~ 8305
Material	SUS304 WPB	SUS304 WPB	SUS304 WPB
Material	The model produced with materials except SUS304 WPB does not perform the shipment to the foreign countries.
Outside diameter (mm)	2.0 ~ 36.0	0.6 ~ 135	3.0 ~ 68.0
Wire diameter (mm)	0.20 ~ 3.20	0.1 ~ 10	0.50 ~ 5.0
Free height (mm)	4.0 ~ 126.0	1.0 ~ 1015	4.4 ~ 585
Allowable load (N)	0.62 ~ 327.32	0.21 ~ 4111.591	4.70 ~ 707.100
Allowable load (N)	Defined by 80% of allowable torsional stress given from JIS B2704.	As a reference value, it is not with a tolerance.	As a reference value, it is not with a tolerance.
Total coils	4.5 ~ 20.0	5.5 ~ 20.5	5.5 ~ 20.5
Direction of wind	Right hand coil	Right hand coil	Right hand coil
Limiting temperature	-30℃ ~ +200℃	-30℃ ~ +200℃	-30℃ ~ +200℃
Low temperature annealing	For performance improvement, after spring formation, it is subjected to low temperature annealing.
Quantity per bag (pcs)	1 ~ 20 (The number of items in a bag differs depending on the model)
Delivery time	Prompt delivery of goods.
All products are compliant with the RoHS directive

Lineup

All 2524 items in the Super Spring series are held in standing inventory for timely delivery.

All products are prepared in small batch packages,

so we can accept and deliver even the smallest orders quickly.

Conventional kits for product development and design as well as tool maintenance.
Optimal springs can be selected without cumbersome calculations or drawings, thus contributing to work streamlining and cost reduction.

Super Spring K series Kits

Product code	Product name	Contents
1239	K series Kits C1 (No.1001~No.1075)	Super Spring K series Compression Spring No.1001~No.1075 There are a couple of springs for each 75 types.


1240	K series Kits C2 (No.1076~No.1127)	Super Spring K series Compression Spring No.1076~No.112 There are a couple of springs for each 52 types.


1241	K series Kits E1 (No.2001~No.2120)	Super Spring K series Extension Spring No.2001~No.212 There are a couple of springs for each 120 types.


1242	K series Kits E2 (No.2121~No.2172)	Super Spring K series Extension Spring No.2121~No.2172 There are a couple of springs for each 52 types.


1236	K series Kits (No.1001~No.1127) (No.2001~No.2172)	Super Spring K series Compression Spring & Extension Spring No.1001~No.1127 & No.2001~No.2172 SET There are a couple of springs for each 299 types.




Super Spring D series Kits

Product code	Product name	Contents
1253	D series Kits C1 (No.5051~No.5175)	Super Spring D series Compression Spring No.5051~No.5175 There are a couple of springs for each 125 types.


1254	D series Kits E1 (No.6102~No.6270)	Super Spring D series Extension Spring No.6102~No.6270 There are a couple of springs for each 85 types.


1259	D series Kits (No.5051~No.5175) (No.6102~No.6270)	Super Spring D series Compression Spring & Extension Spring No.5051~No.5175 & No.6102~No.6270 SET There are a couple of springs for each 210 types.




Super Spring DS series Kits

Product code	Product name	Contents
1255	DS series Kits C1 (No.8001~No.8075)	Super Spring DS series Compression Spring No.8001~No.8075 There are a couple of springs for each 75 types.


1256	DS series Kits C2 (No.8076~No.8153 of end number 1,2,3,6,7,8)	Super Spring DS series Compression Spring No.8076~No.8153 of end number 1,2,3,6,7,8 There are a couple of springs for each 48 types.


1257	DS series Kits E1 (even of No.8502~No.8670 )	Super Spring DS series Extension Spring even of No.8502~No.8670 There are a couple of springs for each 85 types.


1258	DS series Kits E2 (No.8672~No.8786 of end number 2,4,6)	Super Spring D series Extension Spring No.8672~No.8786 of end number 2,4,6 There are a couple of springs for each 36 types.


1260	DS series Kits (No.8001~No.8075) (No.8076~No.8153 of end number 1,2,3,6,7,8)	Super Spring D series Compression Spring & Extension Spring No.8001~No.8075 & No.8076~No.8153 of end number 1,2,3,6,7,8 SET There are a couple of springs for each 123 types.



1261	DS series Kits (even of No.8502~No.8670) (No.8672~No.8786 of end number 2,4,6)	Super Spring DS series Compression Spring & Extension Spring even of No.8502~No.8670 & No.8672~No.8786 of end number 2,4,6 SET There are a couple of springs for each 121 types.



1262	DS series Kits Product code 1260 & 1261 Set	Super Spring DS series Compression Spring & Extension Spring Product code 1260 & 1261 DS series ALL 244 types.

Our Services

We also stock other high quality industrial goods, such as our Super Shaft stainless precision shaft series, screw reinforcement components, and stainless pipes, with a high standard of quality control and a system that ensures prompt delivery.

Secure packaging using cardboard boxes matched to the size of the order,

and inner cartons or packing materials as necessary. Same-day (within 24 hours) delivery upon confirmation of payment.

Our discount rate is depends on the quantity you purchase.

If the catalog and price list is required, please feel free to contact us.
