Radial Drilling Machine Z3032x10/1

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Z3032x10/1 Radial Drilling Machine Characteristics:

With wide range of speed and feed, with manual, power and fine feeds.
The feed of machines are very easily engaged and disengaged at any time.
With safe and reliable feed safety machine, all parts easy operation and change.
All controls centralized on the head stock easy operation and change.
With rapid and accurate hydraulic pre selection of speeds and feeds of spindle.
Main parts are made by machine center which import from KIA with high precision and efficiency, ensuring reliability and high quality.
Integrating technology for casting parts is excellent, adopting casting equipment, ensuring high quality of material for basic parts.
Spindle parts are made by special high quality steel heat treament to be made first class equipment, ensuring high strength and durability.
Main gears are machined by gear grinding, the machine ensuring high precision and low noise.

Standard accessories:

Special accessories:

Model	Z3032x10/1
Max. Drilling capacity (mm)	32mm
Distance spindle axis to column generating line (mm)	300mm ~ 1000mm
Diameter of column (mm)	240mm
Spindle taper	MT4
Spindle travel (mm)	280mm
Spindle speeds range (R/ min)	32 ~ 2500
Spindle speeds series	16
Range of spindle feeds (mm /R)	0.10 ~ 1.25
Spindle feeds	8
Distance spindle nose to working surface of base (mm)	220mm ~ 1000mm
Dimensions of worktable (mm)	600mm450mm450mm
Dimensions of base (mm)	1710mm800mm160mm
Overall Size (mm)	1760mm800mm2050mm
Power of main motor (W)	2200W
G.W / N.W (Kg)	2000Kg / 1600 Kg
Packing Dimensions (cm)	187cm97cm220cm

** All Specification and Design are subject to change without prior notice **
