Home > Products > Maize flour machines > 2016 New Style Pingle Flour Mill Plansifter / Nylon High-Square Plansifter Mesh
2016 New Style Pingle Flour Mill Plansifter / Nylon High-Square Plansifter Mesh
- TIANJIN CHINA
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
2016 High Quality Pingle Flour Mill Plansifter / Polyester High-Square Plansifter Mesh
-
Cheap And High Quality Pingle Flour Mill Plansifter / Flour Sieving Machines High Square Plansifter
-
2016 New Design Pingle Flour Mill Plansifter / Flour Sifting Equipment
-
2016 Newest Hot Selling Pingle Flour Mill Plansifter / Flour Machine Plansifter
-
High Quality Pingle Flour Mill Plansifter / Fsfg Series High Square Plansifter
-
China Wholesale Custom Pingle Flour Mill Plansifter / Multi-Section Plansifter
Product Details
| Condition | New | Place of Origin | Hebei, China | |
| Brand Name | Pingle | Model Number | Maize flour mill | |
| Production Capacity | Depend | Voltage | 220V/380V | |
| Power(W) | 100-1200 | Weight | 2700 | |
| Dimension(L*W*H) | 1780*2410*2430 | Certification | ISO,CE,SGS | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
2016 New Style Pingle Flour Mill Plansifter / Nylon High-Square Plansifter Mesh
1. Display:
2.Equipment Features
High quality steel plates;
Plates adopt laser cutting machine;
Bending and welding adopt numerical control bender and argon arc welding;
The motor configuration is Hengshui motor, the protection grade is IP54, and its insulation class is F;
Screen frame and surface grid adopt aluminium alloy material, its accuracy is high and will not be distorted;
All steel plates are carried on souring and phosphorization, part of them adopt shot blasting at first, then adopt spray paint treatment;
The connecting bolts adopt high strength bolts;
The suspender of high-square plansifter adopts glass fiber reinforced plastics suspender
High-quality clean and quickly to push materials
3.Specifications:
Type | FSFG4*24 | FSFG6*24 | FSFG6*24K | FSFG6*24A | FSFG6*27M | FSFG8*27M |
Bin quantity (piece) | 4 | 6 | 6 | 6 | 6 | 8 |
Screen quantity (piece) | 22-27 | 22-27 | 24-30 | 22-27 | 24-30 | 24-30 |
Sieve area(m²) | 23.04-27.94 | 34.56-41.9 | 38.88-47.31 | 48.96-57.6 | 55.08-65.45 | 73.44-87.26 |
Speed of mainshaft (r/min) | ~245 | ~245 | ~245 | ~245 | ~245 | ~245 |
Tactical diameter (mm) | ~64 | ~64 | ~64 | ~64 | ~64 | ~64 |
Specification of screen (mm) | 640 | 640 | 640 | 740 | 740 | 740 |
Transferrable motor (kw) | Y132S-6-3 | Y132M1-6-4 | Y132M1-6-4 | Y132M2-6-5.5 | Y160M-6-7.5 | Y160L-6-11 |
Dimention(mm) | 1780*2410*2430 | 2550*2410*2430 | 2564*2360*2580 | 2830*2814*2430 | 2885*2566*2580 | 3760*2766*2580 |
Height of sifting box (mm) | 2150 | 2150 | 2300 | 2150 | 2300 | 2300 |
Height of screen (mm) | 1835 | 1835 | 1985 | 1835 | 1985 | 1985 |
Weight(kg) | 2700 | 4200 | 4100 | 4700 | 4950 | 6200 |
4. Pictures for client reference:
5.Application:
1.About us
Professional manufacturer specialized in grain processing project manufacturing
and installation with more than 20 years experience.Main products includes wheat
flour milling machine and maize milling machine. Our products have been exported
to 32 countries and regions such as Egypt, Ethiopia, India, Iran, Vietnam, Brazil etc.
The international Trade Division sets up sales dep., technical engineer dep., after sales
service dep.and documentation and logistical dep., which can manage engineer designing,
installation and service with professional staff.
2.Why chooes us
---Advanced equipments,good quality
---Professional skills,all-related services
---High quality and efficiency technology
---Complete production line,quick delivery
---20 years experience in flour mill industry
---Best solution for wheat and maize processing syste
---The biggest flour mill machine manufacturer and exporter in China
---Exporting to more than 40 countries with a presence world wide
3.Factory Tour
4.Participation in exhibitions
5.Our Market
6.Certification
7.Contact Us
