Slivery-white Color 4-way RF Power Splitters/Dividers(800-2500,800-2700,698-2700MHz)
- Shanghai/Shenzhen/Ningbo
 - T/T Credit Card

You May Like
Product Details
| Place of Origin | Anhui, China | Brand Name | SETSAIL | |
| Model Number | YFTX-RFPS-SW-02-NF |
Standard Exporting Cartons
Product Description
Specifications
We are manufacturer. OEM Service Provided1.Low insertion loss
2.Wide Frequency Range
3.Low VSWR
4.Low -150dBc PIM3
Applications:
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems.
800-2500MHz Cavity Power Splitter
Technical Specification
Model  | YF.APD8025-02N  | YF.APD8025-03N  | YF.APD8025-04N  |
Frequency(MHz)  | 800-2500 800-2700 698-2700  | ||
Insertion loss(dB)  | 3.3  | 5.2  | 6.5  |
| Color | Slivery-white  | ||
VSWR  | 1.25:1  | ||
Power Capacity (W)  | 200  | ||
3rd order IMD  | -150@2×43dBm  | ||
Impedance(ohm)  | 50  | ||
Temperature(deg)  | -35 deg to +60 deg  | ||
RF connector  | N-female  | ||
Relative Humidity  | 5%-95%  | ||
Size(mm)  | 221.1×60.4×20  | 225.4×60.4×18  | 225.4×60.4×18  |
Wight(kg)  | 0.17  | 0.21  | 0.235  |
Pictures:
Company Profile
                    Hefei Setsail Telecom,Co,Ltd (established in 2002) is an Professional Manufacturer of RF Passive Components:Power Spliter, Directional Coupler, 3dB Hybrid Coupler, Combiner, Dummy Load/Termination, Attenuator, Duplexer, Isolator, Cable, Connector and Antenna. 1. Hefei Setsail Telecom,Co,Ltd is established in 2002.located in Hefei National Hi-tech Industry Development Zone.We focus on Microwave Technology Research,RF,Microwave Components and System Industry Development.Our products are widely used in communication network,satellite orientation,radar and military field.We offer a highly diversified product line that serves top tier telecom,satellite companies. 2. Products include 10 series and 100 designs with their own property right and authority approval.The products line have Hybrid Coupler,Power Splitter,Directional Coupler ,Coaxial Attenuator,Coaxial Termination,Cable Assembly,Connector,Arrester,Filter,Duplexer,Combiner and so on .Customer designs (OEM/ODM) are also available. 3. Headquarters of Setsail is located at hi-tech developing district in Hefei Anhui,includeing two factories, At the same time,Setsail's market network has been all over the world. 4. Setsail company has a tremendous fellowship that is compased of many high-level technologists .And also has established a research institution which cooperating with some famous universities.(University of Science and Technology of China.) 5.All the staffs are filled with confidence ,attending the market cpmpetition and offering clients the exquisite technology,reasonable price,excellent quality and best service.
