PF Series Stone Crushing Equipment Impact Crusher
- Shanghai Qingdao Tianjin
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Impact Crusher | |
| Capacity(t/h) | 15-350 | Place of Origin | Henan, China | |
| Brand Name | Great Wall | Model Number | PF |
Product Description
Specifications
1. large capacity2. long service life
3. low power consumption
4. convenient maintenance
PF series Stone Crushing equipment Impact crusher
Usage and Application
The stone impact crusher is used for primary, secondary, fine crushing mining and rocks (for example, the granite, marble, and limestone) materials with compressive strength less than 350 MPa. It is widely used for sand and rock producing in the industry of roads, railways, water conservancy projects, electricity power, building materials and so on.
Energy Saving ImpactCrusher Popular Product Working Principle
The materials are crushed by impact energy produced in the crusher. When the materials enter the zone of the blow bar, they are flung into the impact equipments via the high-speed impact of the blow bar. These materials will be re-crushed after rebounding into the impact plate. The process goes on until the materials are crushed to the required size and then will be discharged from outlet of machine.
PF series Stone Crushing equipment Impact crusher
Features
1. Cubic shaped end products;
2. Adjustable end products sizes, simple crushing process;
3. High chrome and abrasion resistant blow bar, powerful impacting force;
4. Non-key connected, easy maintenance, economical and reliable;
5. Compact construction, high efficiency.
2012 Hot sale PF series impact crusher Main Specifications
Model | Rotor | Feed | Max. Feeding | Capacity | Motor | Weight | Overall |
PF-1007 | Φ1000×700 | 400×730 | 250 | 15-50 | 37-55 | 9.5 | 2400×1560×2660 |
PF-1010 | Φ1000×1050 | 400×1080 | 300 | 50-80 | 55-75 | 13.2 | 2440×2250×2630 |
PF-1210 | Φ1250×1050 | 400×1080 | 300 | 70-130 | 110-132 | 16.5 | 2700×2340×2870 |
PF-1214 | Φ1250×1400 | 400×1430 | 300 | 90-180 | 132-160 | 19.5 | 2700×2695×2900 |
PF-1315 | Φ1320×1500 | 860×1520 | 350 | 120-250 | 180-260 | 24.8 | 2860×2800×3050 |
PF-1320 | Φ1320×2000 | 860×2030 | 500 | 160-350 | 300-375 | 30 | 2870×3350×3090 |
