Home > Products > Hydraulic Cone Crusher > Hydraulic Stone Breaker
Hydraulic Stone Breaker
- Tianjin Shanghai Qingdao
- T/T
You May Like
Product Details
| Condition | New | Type | Cone Crusher | |
| Capacity(t/h) | 1-1402 | Place of Origin | Henan, China | |
| Brand Name | Great Wall | Model Number | HCC |
Product Description
Specifications
Hydraulic Stone Breaker1Special design
2High reliable
3Large capacity
4Super fine
Great Wall Make Great Machine
Hydraulic Stone Breaker
1. Hydraulic Cone Crusher Usage and Application
The HCC Hydro Cone Crusher is widely used for secondary and fine crushing in the fields of mining, building materials, metallurgy and so on.
2. Hydraulic Cone Crusher Features
1. The crushing chamber is special designed according to particles-layer- pressure principle. The special chamber and the suitable rotary speed improve crushing ratio and capacity, so does the cubic product percentage.
2. With hydraulic protection and hydraulic chamber cleaning, the machine is high-automatic. If something abnormal happens, the machine will lift up the cover and discharging the materials automatically.
3. The mantle and bowl liner are made by high abrasion materials.
4. It is adjusted by hydraulic device and lubricated by diluted oil.
3. Hydraulic Cone Crusher Main Specifications
Model | Chamber Size | Max Feeding Sizes(mm) | Adjusting Range of Output Size(mm) | Capacity | Motor Power (kw) | Weight (t) | Overall Dimension |
HCC36B | Fine | 85 | 9~22 | 46~94 | 75 | 14.2 | 2656×1746×2241 |
Coarse | 150 | 13-38 | 61~168 | ||||
Extra Coarse | 152 | 25-38 | 122~168 | ||||
HCC36D | Fine | 35 | 3~13 | 28~93 | 14.7 | ||
Medium | 65 | 5~16 | 37~103 | ||||
Coarse | 85 | 6~19 | 61~133 | ||||
HCC51B | Fine | 115 | 13~31 | 112~189 | 160 | 25.9 | 2983×2354×3156 |
Medium | 178 | 16~38 | 136~261 | ||||
Coarse | 205 | 19~51 | 177~359 | ||||
Extra Coarse | 220 | 25~51 | 243~369 | ||||
HCC51D | Fine | 54 | 3~16 | 37~168 | 26.4 | ||
Medium | 76 | 6~16 | 84~168 | ||||
Coarse | 89 | 8~25 | 112~234 | ||||
Extra Coarse | 113 | 16~25 | 215~243 | ||||
HCC66B | Fine | 178 | 16~38 | 186~337 | 220 | 50 | 3911×2870×3771 |
Medium | 205 | 22~51 | 266~430 | ||||
Coarse | 228 | 25~64 | 308~654 | ||||
Extra Coarse | 313 | 38~64 | 444~664 | ||||
HCC66D | Fine | 60 | 5~13 | 93~215 | 51 | ||
Medium | 76 | 6~19 | 140~289 | ||||
Coarse | 113 | 10~25 | 196~346 | ||||
Extra Coarse | 125 | 13~25 | 261~346 | ||||
HCC84B | Fine | 236 | 19~38 | 392~748 | 315 | 88 | 4613×3302×4638 |
Medium | 284 | 25~51 | 626~1028 | ||||
Coarse | 314 | 31~64 | 813~1308 | ||||
Extra Coarse | 391 | 38~64 | 906~1402 | ||||
HCC84D | Fine | 89 | 5~16 | 196~420 | 90 | ||
Medium | 113 | 10~19 | 365~523 | ||||
Coarse | 151 | 13~25 | 468~617 | ||||
Extra Coarse | 172 | 16~25 | 523~673 |
Note: Any Change of technical data shall not be advised additionally.
