High Temperature Refractory Insulation Box Liner
- ANY CHINA PORT
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Refractory Material Products Boards for Boiler
-
Heat Insulation Mineral Fiber Al2o3 Wool Fiber
-
St(standard) Grade and Heat Insulation Application Ceramic Fiber
-
Fire Resistance and Heat Insulation Ceramic Fiber
-
Fireproof Material for Cremation Furnace for Sale
-
Insulated Cooler Liner Material for Furnace / Kiln / Boiler
Product Details
| Grade | HA (High Aluminum) | Application | Liners Of Industrial Furnace | |
| Thickness | 10-50mm | Width | 610/1220mm | |
| Length | 3600/7200/14640mm | Chemical Composition | AL2O3+SIO2 | |
| Working Temperature | 1350 | Fiber Diameter | 3-5um | |
| Shrinkage (1800 ℉, 3h) | 3%(24 Hours) | Thermal Conductivity | 0.055-0.180(W.k.m.) | |
| Model Number | High Pure | Brand Name | HENGRUI | |
| Place of Origin | Henan, China |
Product Description
Hengrui high temperature refractory insulation box liner is made of special ceramic fiber through double needle-punching processing. The double needle-punching techniques improve the degree of fiber intertexture, and the performance of delamination resistance as well as tensile strength. The high temperature refractory insulation box liner does not contain any bonding agent and with the characteristics of stable chemical performance, resistance to the erosion of most chemicals,The physical property like refractory and insulation keep same when meet with oil,water or steam.
◊ Excellent chemical stability,nonflammable .
◊ Low thermal conductivity and good insulation.
◊ Good tensile strength and springiness.
◊ Excellent performance of soundproofing Good obstructing and resistance to heat-shock.
| high temperature refractory insulation box liner | HR1050 | HR1260ST | HR1260HP | HR1350 HA | HR1430 Zr | HR1600 PMF | |
| Classification Temperature(°C) | 1050 | 1260 | 1260 | 1350 | 1430 | 1600 | |
| Working Temperature(°C) | 900 | 1050 | 1050 | 1200 | 1250 | 1400 | |
| Density(KG/m3) | 96-160 | 96-160 | 96-160 | 96-160 | 96-160 | 96-160 | |
Liner Shrinkage (24h,128 Kg/M3) | ≤2.4 (900℃) | ≤2.3(1000℃) | ≤2.4 (1050℃) | ≤2.2 (1150℃) | ≤3 (1250℃) | ≤1.5 (1400℃) | |
Tensile Strength Kpa(128Kg/M3) | 40 | 80 | 80 | 80 | 80 | 100 | |
Thermal Conductivity Rate(128 Kg/M3 ,W/m.k) | 400 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | - |
| 800 | 0.16 | 0.16 | 0.16 | 0.16 | 0.16 | 0.16 | |
| 1000 | - | 0.23 | 0.23 | 0.23 | 0.21 | 0.20 | |
| Chemical Composition(%) | Al2O3 | 42-44 | 45-46 | 47-49 | 52-55 | 38-42 | 72-75 |
| Al2O3+SiO2 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | |
| ZrO3 | -- | -- | -- | -- | 15-17 | -- | |
| Other | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | |
thermal insulation material /wool for oven
We can provide free samples for customers
We can delivery goods quickly in 2-7 days
We can do OEM for trading company
