New design Doubling winder machine and Mixing yarn winding machine
USD $10,000 - $40,000
/ Set
1 Set(Min.Order)
- Shanghai
- Credit Card
You May Like
Product Details
| Condition | New | Application | mixing multiply yarns winding | |
| Automatic Grade | Semi-Automatic | Production Capacity | 300-1000Meter/min | |
| Place of Origin | Jiangsu, China | Brand Name | TANGSHI | |
| Model Number | TS008A | Voltage | 0.18kw/spindle | |
| Power(W) | 0.18KW/Spindle | Dimension(L*W*H) | L 1920 x W 850 x H 1600/section | |
| Weight | 300KGS/section | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Machine Application:
TS008A Multi-ply Yarn Winding Machine, it's for multi ply yarns mixing winding together, can wind like 2-12 plys yarns on the bobbin, can suit like cotton yarn, wool yarn, fiber yarn, polyester yarn and etc.
Parameters:
1. Master digital controller;
2. each spindle run separately with a motor drive;
3. Length counter installed on each spindle;
4. Auto stop device;
5. adjust speed by inverter;
6. uniform tensioner;
Specification:
Technical parameters:
| Spindle No. | Max 36 spindles |
| Spindle Gauge | 420MM |
| Spindle NO. per group | 4 spindles |
| Winding yarn Plys | 2-12 plys |
| Winding Speed | ≤500m/min |
| Driver: | Each spindle with a motor driving |
| Tensioner: | tabletting tension |
| Auto Stop Device | Yarn sensor |
| Traverse Gauge | 6-10' inch |
| Air Splicer | Optional installed |
| Blower cleaner | Optional installed |
| Brake system | Optional installed |
| Dimensions | L 1920 x W 850 x H 1600 mm (one group size) |
