Top sale, 10Tons Hydraulic decoiler with coil car

FOB Price

USD $10,000 - $12,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Decoiler
Tile Type	Other	Use	Other
Place of Origin	Jiangsu, China	Brand Name	BN
Model Number	Feeder Machine	Power(W)	5.5 Kw
Voltage	380V	Dimension(LWH)	2.8m1.6m1.5m
Weight	10tons	Certification	CE ISO
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas

Compositions

5T coil car	1 unit
5T hydraulic decoiler	1 unit

Structures

5Tons coil car
Coil weight (Max)	5000kg
Inter diameter of coil	:480mm-560mm
Working by hydraulic pressure	8-12Mpa with connect with the decoiler hydraulic unit
Working lift journey	Maximal 250mm
Working function	forward and reverse movable
Move journey	maximal 3 meters
Quantity:	1
Color:	blue or base on customer request

5T hydraulic decoiler
Coil weight (Max)	5000kg
Inter diameter	460mm-560mm
Maximal out diameter	1250mm
Oil cylinder dia	120mm
Coil width (Max.)	1250mm
Working speed	0-15m/min adjustable
Main motor power	5.5KW AC motor
Hydraulic power	4kw
Frequency converter brand:	Yaskawa
Quantity	1
Color	blue or base on customer request

Materials&Equipment

Lubricants	will be provided before the commissioning of the equipment, the specification, type of feeding, and the consumption will be declared in operation manual.
Liquid for hydraulic pressure stations	the specification will be provided in operation manual
Calibres, gauges and wrenches for equipment adjustment and setup (including for switching between profile heights)	will be included in the delivery

Packing & Delivery

Packing	suitable of ocean transportation
Delivery	Delivery of the equipment	within not more than 1 months from the transfer of the advance payment.
	Delivery of the work	within not more than 2 months from the transfer of the advance payment.

Connections&safety

Electrical connection properties for equipment units and control assembly	to be declared
Safety switches and emergency alarm	must be provided
Other required connections	to be declared
Noise level	low noise
Hydraulic pressure stations:	was mentioned in above spec
