LTRG-60A Hot Sale Automatic Super Glue Filling And Packing Machine

LTRG-60A  super glue filling and packing machine

         This machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement. PLC controller and color touch screen are applied and made it possible for programmable control of the machine. It can perform the filling for ointment, cream jellies or viscosity material, sealing or tail folding, batch number embossing (include manufacture date) automatically. It’s ideal equipment for plumbum tube, plastic tube and laminated tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.

Feature

1. With 9 stations and matching with manipulator, the machine is able to meet different type of tail folding, sealing requirements of plumbum tube, Alu tube, plastic tube and laminated tubes. It is a multi-purpose machine.
2.  Tube feeding, eye marking, tube interior cleaning (optional), material filling, sealing (tail folding), batch number printing, finished products discharging can be performed automatically (the whole procedure).
3. Servo control makes it precise and convenient to adjust the filling amount by touch screen.
4. According to the different length of the tube, height of tube chamber can be adjusted easily by motor. With external reversal feeding system, makes tube charging more convenient and tidy.
5. The mechanical linkage photo sensor precision tolerance is less than 0.2mm. The chromatic aberration scope between tube and eye mark is reduced.
6.    Photo-electronic, electric, pneumatic integrative control is applied with the machine. No tube, no filling. It gives an alarm when low pressure occurs. The machine stops automatically if tube error or open the safety door.
7. Three-layer jacket instant heater with inside air heating, it won’t damage the pattern on outer wall of tube and achieves firm and beautiful sealing effect.

Main technical Data

Model

LTRG-60

Tube Material

Plastic tube, laminated tube,Aluminum Tube

Tube Diameter

Φ5mm-Φ50mm

Tube Length

50-240mm (customizable)

Filling Volume

5-250ml/piece (Adjustable)

Filling Accuracy

≤±1%

Product Capacity (Pcs/min)

60pcs/min

Air Supply

0.55-0.65Mpa

Motor Power

4kw (380V/220V 50Hz)

Heat Sealing Power

5kw

Overall Dimension(mm)

2807*1240*1900mm (L*W*H)

Machine Weight (kg)

1100kg
