Home > Products > 01.Plastic extruder > plastic polypropylene machine for PP pipes
plastic polypropylene machine for PP pipes
- 2 Set / Sets per Month
- Qingdao Port
- T/T
You May Like
Product Details
| Condition | New | Application | Pipe | |
| Plastic Processed | PP | Screw Design | Single-screw | |
| Automatic Grade | automatic | Place of Origin | Shandong, China | |
| Brand Name | Hanhai | Model Number | SJ120 | |
| Voltage | 380V 50HZ | Power(W) | 150KW | |
| Dimension(L*W*H) | 25*3*3 | Weight | 5000 | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
plastic polypropylene machine for PP pipes
/en/
/
contact person:Tracy Guan
Skype:tracyroseguan
Mobile:+8613864850419
This producton line has production capacity of churnng out diameter16mm-160mm PPR pipe continuously with assembling the special high-speed single extruder, which is distinguishingly designed with co-extrusn die head, the production speed can reach 20m/min, The PPR pipe made by the this facility has such features of smooth on both sides, week internal stress, anti-corrosion, anti-corosion,antibiosis,shock resistane,aging resistant, no leakage, light weight, economc investment, convenient application and so on. This facility can also be used to produce the HDPE silicone core pipe,PB pipe,PE pipe,PEX pipe,etc.
Theeconomic and technical norms of the finished products are all reached the international standards after been detected by National chemical construction test center, which are the first choices to replace the traditional galvanized pipe and applicable to so many fields, such as conveying the hot and cold water,central-heating,and floor heating.
Main technical parameters
Item
| SJ-30
| SJ-45
| SJ-65
| SJ-90
| SJ-120
| SJ-150
|
Length Diametr Ratio(L/D)
| 25-33
| 25-33
| 25-33
| 25-33
| 25-33
| 25-33
|
Main motor power (KW)
| 2.2-7.5
| 7.5-2.2
| 18.5-55
| 55-185
| 90-280
| 110-300
|
Heating Power(KW)
| 5-8
| 6-12
| 12-18
| 16-40
| 20-60
| 30-80
|
Cooling Mode
| Wind&water cooling
| |||||
Max.extruding capacity
| 18
| 60
| 180
| 450
| 650
| 950
|
Reference Pictures:
standard sea safe film and wooden cased for small spareparts by sea or train.
Our services:
Turn key project.
Technical documents
We will offer you all necessary documents, e.g. general layout plan, water scheme, electrical diagram and user manual after the contract is executed.
Arrangement for inspection, installation and testing work
a.After being informed machines ready for inspection, customer can send engineers to our factory.
b.After the machines are delivered to customer’s factory;We will send one or two technicians to the factory after preparation work is completed;Technicians will be responsible for guide on-site installation and testing machines.
c.Meanwhile technicians will give free training lessons to labors in customer’s factory.
Qingdao Hanhai Plastic Machinery Co.,Ltd. is located in Jiaozhou city, Shandong province, China. It’s high-tech manufacturer specializing in research & development and producing extrusion equipment. Company has good R & D employees and experienced mechanical , electrical commissioning engineers. The main products are including:
UPVC, PPR small diameter pipe extrusion line.
Large diameter PE water pipe, MDPE gas pipe, UPVC pipe extrusion line.
PVC,PP,PE,ABS,PC,PS sheetboard extrusion line.
PVC window profile, ceiling , window sill, siding plate extrusion line.
PVC, PP, PE wood plastic door panel extrusion line.
PE-RT hot water pipe, PEX underground warm pipe, PP-R, PP, PP-B new water pipe extrusion line.
PE Collective fiber glass pipe, PVC-C high voltage cable protective pipe, PE/PVC cross-section communication cable pipe extrusion line.
All kinds of conical twin screw extruders, parallel twin screw extruders,single screw extruder.
We have more than 15 years producing experience . Can supply all technology information you need.
For more information pls contact :Tracy Guan
Mobile/whatsapp/viber /wechat:+86-13864850419
skype:tracyroseguan
Contact Us
- Qingdao Hanhai Plastic Machinery Co., Ltd.
- Contact nameTracy Guan Chat Now
- Phone86-532-85217222
- AddressJiaoxi Industrial Park , Qingdao, Shandong
