YG8 Tungsten Carbide Strips and Bars Supplier With Various Size Options
- China Port
- T/T Credit Card
You May Like
-
100% Virgin Material Hign Wear Resistant Tungsten Carbide Plates/blocks/blanks for Shapping Tools
-
Silicon Carbide Plate for Cutter Tool
-
Woodworking Tools Tungsten Carbide Strips
-
Un-standard Carbide Product Tungsten Carbide Flat for Cutting Tools
-
K20 Tungsten Carbide Strips in China With High Quality
-
High Hardness Hard Metal Block for Canton Fair
Product Details
| Place of Origin | Hunan, China | Brand Name | GT strips and bars | |
| Model Number | various types | Dimensions | length*width*thickness |
Product Description
1. YG8 Tungsten Carbide Strips and Bars Supplier with various size options
*Detailed Description:
Production in a range of woodworking tools,plane,hop cutter,sub-cutter etc.
Our company uses advanced molding process in order to produce rarious types of strips/blanks to meet every clients requirements.
| Properties and applications of tungsten carbide for strips/blanks | ||||
| Grade | Density | T.R.S | Hardness | Performance & application recommended |
| g/cm3 | MPα | HRA | ||
| YG6 | 14.9 | 2150 | 90 | Good wear resistance, used for hard wood, used for processing original wood, aluminum section bar, brass rod and cast iron. |
| YG6A | 14.9 | 1860 | 92 | Has wear resistance higher than YG6, used for processing hard wood, original wood, aluminum section bar, brass rod and cast iron. |
| YG8 | 14.7 | 2320 | 89.5 | Wear and percussion resistance , used for processing hard wood, soft wood, ferrous and non~ferrous. |
| YS2T | 14.5 | 2350 | 92 | Fine carbide, High wear resistance, high bending strength, high resistance to bonding, high thermal strength. Machining of refractory alloys, stainless steel and high manganese steel, etc. |
| YM10X | 14.5 | 2150 | 92.2 | Wear resistance and strength comparatively higher, suitable for processing cast iron, non~ferrous,metal and non~metallid materials. |
| DIMENSIONS | ||
| (unit):mm | ||
| L | W | S |
| 200 | 200 | 3~65 |
| 150 | 150 | 3~45 |
| 150 | 100 | 3~65 |
| 150 | 130 | 3~65 |
| 150 | 80 | 3~65 |
| 120 | 120 | 3~65 |
| 100 | 100 | 3~65 |
| 100 | 50 | 2~65 |
| 100 | 45 | 2~65 |
| 80 | 55 | 2~65 |
| 80 | 40 | 2~65 |
| 70 | 35 | 2~50 |
| 45 | 25 | 2~20 |
| 35 | 19 | 2~30 |
| 20 | 20 | 2~20 |
| 18 | 13 | 2~20 |
| … | … | … |
*Packing

P.S: How to get exactly quotation based on clients requirements:
- Specification ( like length x width x thickness,OD,ID,shape,angle etc.)
- Tungsten carbide grade, or chemical composition
- surface condition: sintered blank or fine grinding
- tolerance on dimension ( if you have)
- If you are not quite clear about which tungsten carbide grade is suitable, please provide us the application of the carbide products, and our professional technicians will suggest you a suitable one.
2.Why Choose us ?
We are a tungsten carbide manufacturer, located in Zhuzhou City, Hunan Province, China. Our production are exported to UK, European, Japan, Taiwan and South-east Asia etc.
The products are popular in the market because of their good quality, moderate price and fast delivery.
3.ZZGT Main Products:
1).carbide saw tips
2).carbide die cores
3).carbide brazed tips
4).carbide milling inserts
5). carbide disc cutters
6).carbide strips and plates
7).carbide mining and drilling tool parts
8).carbide rings and rollers
9).carbide wear resistant parts
10).carbide rods
4.Product Size:
All products according to ISO standard. For any other sizes or odd sizes,we are able to custom made according to clients' requirements or drawings.
5.Our advantage:
*100% quality guarantee(ISO9001)
*fexible payment terms(L/C, T/T, western union etc.)
*competitive price,10 years manufacturing experience
*fast delivery (7-10 workdays)
6.Factory Workshop Show:
7.Processing Chart:
8.Shipping Terms:

We will exert our best efforts to repay your appreciation for our products!
Please feel free to contact us as your convenient :)
Yeva.Yang (Sales Dept.)
Contact Us
- Zhuzhou Gingte Cemented Carbide Co., Ltd.
- Contact nameYeva Yang Chat Now
- Phone86-731-28107372
- AddressNo.3, Changjiang South Road, Tianyuan District, Zhuzhou City, Hunan Province, China, Zhuzhou, Hunan
