TV Standard

Fully SD/HD Tuner DVB-T/T2,  SD/HD MPEG2 and  MPEG4 AVC H.264

Video Resolution

Full HD tuner DVB-T2,support up to 1080P

Video System

Automatic PAL/NTSC conversion

Video Ratio

Aspect ratio 16:9 and 4:3

Channels Number

1000 channels memory

OSD Language

OSD language: English, Thailand, Russia, Spainish more please visit

EPG

Small windows screen picture with EPG graphic menu,7-Day EPG function

Channel Search

Auto search & Manual search function

Software upgrade

Software upgrade via USB

Teletext

Support teletext/ subtitle/audio language selection,VBI Teletext,Teletext/ Bit Map subtitle

Save Channel

Automatic save for last channel

LCN

Support Logic Channel Number(LCN)

1.Main Chip Sets

Flash Memory

32MB Serial Flash

DDR2 Memory

512MB

2.Tuner

Input Frequency

VHF:  174~230MHz,UHF: 470~862MHz

RF input Level

-20~-83dBm

RF Bandwidth

6MHz-7MHZ and 8MHZ

Modulation

QPSK,16QAM,64QAM,256QAM

3.USB Decode

DVR supporting

Stereo/MONO/Left/Right

Media Supporting

USB2.0 Port, playback the media in USB flash disk or USB HDD

USB2.0 HOST

DVR with USB HDD, Time shifting with USB HDD

4.Multimedia

music

MP3,WMA


JPEG,BMP,PNG

Video

5.Video Decode

Decode Format

MPEG-2 MP@HL, MPEG-4 SP, DIVX1 3.11(Optional), 4.X, 6.X,FLV Format,

 H.264MP@HL, VC-1,RM&RMVB(Optional)

 Output Format

 1080p,1080i,720p,576p,576i,480p,480i

Aspect Ratio

4:3/16:9/Letterbox/ selectable

Output Port

CVBS and HD Out

6.Audio Decode

Decode Format

MPEG-1,MPEG-2 (Layer I/II),MP3, AC-3(Optional),E-AC-3(Optional),AAC-LC,HE-AAC 5.1

Audio output

RCAX2(L/R) + HD Out (Audio)

7.AV Output

Video Bandwidth

5.5MHz(-3dB)

Video Impedance

75Ω

Video Voltage Level

1.0 Vp-p

Audio Freq. Range

20~20KHz

Guard internal

1/4,19/128,1/8,19/256,1/16,1/32,1/128

Pilot pattern

PP1-PP7

Power Supply

DC(10V-26V)

Hardware interface

DC input 12V, 2 Antenna input, USB, HD out, AUX AV in, CVBS AV out, IR sensor, Power Indicator

Audio format

ISO/IEC14496-30,AAC,AAC+

FFT

1K,2K,4K,8K,16K,32K

Power

2 W

Video resolution

576i,576p,720p,1080i and 1080p

Audio Impedance

600Ω

Audio Voltage Level

2V rms(5.6Vp-p)
