VCAN0928 7"car lcd monitors Multi-Language OSD Standard VGA (15 pin D-SUB RGB) input,12V DC power

Specifications

VCAN0928 7"car lcd monitors Multi-Language OSD Standard VGA (15 pin D-SUB RGB) input,12V DC power

Features

l  Adopt industrial LCD screen, with native resolution of 800*480, 7"car lcd monitors

l  High contrast and brightness, wide viewing angle, which greatly improve the image layering.

l  Standard VGA (15 pin D-SUB RGB) input,12V DC power. 7"car lcd monitors

l  Can support almost all kinds of resolution 7"car lcd monitors

l  Low radiation and consumption.  7"car lcd monitors

l  High reliability, good stability, especially for work in harsh environments.

l  Auto astern switch video function  7"car lcd monitors

l  Multi-Language OSD and User Guide.

l  Easy to install and maintain , with vesa hole

*7″Digital TFT Monitor

*Description: 7″TFT Monitor

*Case/Bezel Color: Black 7"car lcd monitors

*Display Type: 16:9 Ratio 7″Active Matrix TFT

*Active DisplayArea: 152.4(H) X 91.44(V) mm

*Native Resolution: 800 x 480 @ 60Hz 7"car lcd monitors

*HDMI interface input can support 1080i/ 1080P  , 480i/ 480p , 576i/576p

*Sychronization Range: 30-80 KHz horizontal, 55-75 Hz Vertical

*Pixel Pitch: 0.1905(W) X 0.1905(H) mm

*Pixel Response Time Rise + Fall (Typically): 12ms

*Plug and Play: VESA DDC 1/2B

*On Screen Display (OSD): Remote OSD

*Colors: 16.7 million 7"car lcd monitors

*Brightness: 350 cd/m2

*Contrast Ratio Typically: 800:1

*ViewingAngle Horizontal (left/right): 140° (70°/70°)

* (From Centre, CR>=5) Vertical (up/down): 110° (60°/50°)

*Backlight Lamp life Hrs to 1/2 brightness: 50,000

*Operating System: DOS/Windows  9XME 2KXP  7 Vista NT CE / LINUX / Mac,etc.

Monitor size  :179 ( L) X120 ( W) x30 ( H ) MM 7"car lcd monitors

*Shipping Carton Dimensions: 300 x 218 x 85(mm)

*Provider Weight (approximately)Monitor/Shipping: 2kg

*Power Supply: External: 85-265VAC, 50-60 Hz

*Power Consumption: Max 8W Typ car monitor

*Temperature Range: Operating:-10°C-60°C,  Storage:-20°C-80°C

*Relative Humidity Non Condensing: Operating:10%-90%,

Storage 5%-90% 7"car lcd monitors

* One year warranty , three years free main .

*AgencyApprovals: CE, ROHS,FCC

Accessories

VGAcable 7"car lcd monitors

HDMI cable

AV cable

Remote 7"car lcd monitors

Power SupplyAdaptor

Power Lead(US,EU ,UK etc type)

User Manual (English)  car lcd monitor

Bracket
