Excellent weather-ability ASA coated synthetic resin roof tile

Excellent weather-ability ASA coated synthetic resin roof tile

UOI brand synthetic resin roofing tile is the patented production which adopt GELOY ASA super weather resistant enginering plastic from GE PLASTIC, USA.

Features of Synthetic Resin roof tile :

1. GELOY ASA provide the sheets excellent weather resistance and color stability , long life span up to 25--40 years and 10 year free from color fading .

2. Decorative ability, bring the roof fantastic wavy look and multi-dimensional effect.

3. Good load-carrying ability and anti-impact resistance  , the test show no crack happened  after 1 kg steel ball drop from 3 meters on sheet.

4. Excellent corrosion resistance  , free from corrosion of varoius chemical substances such as acid ,alkali and salt .

5. Heat insulation , the coefficient of heat conductivity  is 0.325W/M.K, which is 1/310 of clay tile and 1/5 of cement tile , it can reduce cooling costs in your home or office .

6. Good fireproofing performance , according to GB8624-2006 fireproofing ≥class B.

7. excellent waterproof performance , no water absorb and seep.

8. Green and environment friendly , dont contain asbestos and any redioactive element , can be recycled.

9. Easy to install , 960mm effective width and customized length ensure fast installation .

10. Self-cleaning performance , it dont absorb dust and very easy clean by rain.

Accessory :

main ridge tile ; diagonal ridge tile ; three-way ridge tile , fittings .

Application :

residential homes ,villa , pavilions ......

Specification :

Thickness: 3.0mm ; 2.5mm

Total width : 1050mm ; effective width: 960mm ;

Wave height : 30mm ; wave span : 160mm ; wave  pitch : 220mm

Length : customized but must be a multiple of wave pitch.

Color : dark red ; brick red ; gray ; jasper ; blue
