TE254(N) Tractor

Drive type

4*4

Overall dimension(L * W * H)

3225*1240*1900

Wheelbase (mm)

1639

Track(front/rear)

1215/960-1460

Track(front/rear) regulating method

Fixed/stepless

Min.Ground clearance(mm)

270

Min.operating weight (kg)

1400

Counterweight (max)(front/rear)

80/124

Gears(forward/reverse/creeper)

8+2/8+8

Theoretical speed of each gear(forward/reverse)

1.72-26.02/2.25-10.39;1.72-26.02/1.61-24.24;

Engine

Brand

Laidong, Jiangdong, lijia

Engine type

In-line , water cooled, four-stroke

Intake mode

Natural intake

Number of cylinders

3

Bore

85

Stroke

90

Displacement(L)

1.53

Engine rated power kW@rpm

18.8

Rated speed

2350

Air cleaner type

Dry or wet type

Type of cooling system

Water-cooled

Max. Torque@ revolving speed (rpm)

≥88/1650±100

Specific fuel consumption at rated conditions (g/kW.h)

≤278

Fuel tank capacity (L)

17

Steering brake system

Type of steering system

Hydraulic

Type of steering gear

Cycloid orbitrol steering gear

Type of braking system

Shoe type

Transmission system

Clutch type

Double action

Gearbox type

Two-axis mechanical gearbox

Gearbox shift mode

Shift sleeve +sliding gear

Type of central transmission

Spiral bevel gear type

Final transmission mode (front/rear)

Built-in type, single-stage spur gear

Walking system

Frame type

Frameless

Working device

Type of hydraulic suspension system

Open-center, separated type

Type of linkage

Three point rear linkage

Linkage classes

Class 0 or class I

Lift capacity(610mm point))(kN)

4.2

Regulating mode

Positioning control and floating control

Type of PTO shaft

Non-independent type

The number of PTO shaft splines

6 splines/8splines

Outer diameter of PTO shaft spline

φ35/φ38

PTO shaft speed

540/760 or 540/1000

Hydraulic system

Hydraulic output flow (L/min)

26
