4.5ton wheel drived loader

Specifications

Quick Details

Packaging & Delivery

Specifications

1 With humanized equipments
2 Low fuel consumption
3.Low noise
4 Hydraulic dual-variable
5.Full hydraulic steering sys

• ·  Max.dumping height                2900mm
• Max.dumping distance              900mm
• Max.lifting height                    3700mm
• Min.ground clearance               230mm
• Distance between axles            2070mm
• Tread                                     1430mm
• Overall dimensions(L*W*H)       5000*1600*2650mm
• Engine  model                          4100
• Rated   power                           44KW
• Rated  revolution                       2200r/min
• Working pressure                      16Mpa
• Max.flux                                 63ml/r
• Total Weight                          3700kg
• Rated loading mass                 1600kg
• Gradeability                             25%
• Min.walking speed                    10km/h
• Max.breakout force                    23kn
• Min.rotary radius                      5000mm

Performance characteristics:

1.Single-cylinder 28hp,24v,with smooth discharge,low noise,less oil consumption,the power transmission system is driving and reliable.

2.Novel appearance and model,capacious operator cabin,favorable eyeshot.

3.Hydraulic system with steering preferential,with high efficiency and can save energy,the dynamaic performance of which is better.

4.Convenient back cover for repairing,centralized lubricating system,which is comvenient to maintain and upkeep.

5.Fork-type carriage,the stability of the complete appkiance is good,and  the structural strength is high.

6.Ascendant performance of complete appliance,with extraordinary operation efficiency.

7.With which many kinds of optional compinents can be matched to meet requirements of different users.

Update Date:2010-10-19 02:55:46
