LIGHT FARM TRACTOR/CRAWLER TRACTOR/MINI TRACTOR/TRACTOR

FOB Price

USD $6,000 - $11,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Crawler Tractor
By wheel	Other, CRAWLER	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	60HP
Certificate	Other, ISO9001	Brand Name	VOWO
Model Number	502	Place of Origin	Hunan, China
After-sales Service Provided	No overseas service provided

A farm tractor can be considered the most necessary piece of farm equipment a farmer should

have. It performs a variety of farm tasks such as plowing, tilling, harrowing, shoveling, planting,

hauling, transporting, lifting, and providing power supply.

1. With hydraulic turning and automatic transmission, it’s simple and comfortable for operating,

travelling is easy to control, and turning is flexible. Right hand controls the turning, left hand

controls the forward and backward travelling and the speeds as well as the up and down of the

tools.

2. The machine is of compact structure and convenient for maintenance.

3. High adaptability, it can be operated on the water fields, dry fields and slope fields, suitable

for plain areas and mountain areas.

4. Strong power, strong grade ability, it can pass the ridges conveniently and flexibly.

5. It’s of multi-purposes with optional tools, such as rotary cutters for dry fields, rotary cutters for

water fields, tie ridgers, furrowers, ploughs etc.

6. The position of driving wheel is high, with high min. ground clearance, suitable for deep mud

fields.

MODEL	NF-502
PRODUCT NAME			LIGHT CRAWLER TRACTORS
OVERALL DIMENSIONS	LWH(MM)		300014002150
WEIGHT	(KG)		1240
MINI GROUND CLEARANCE	(MM)		400
ENGINE SPECIFICATIONS	ENGINE MODEL		YD4JT2
	ENGINE TYPE		DIRECT INJECTION,VERTICAL,WATER- COOLED,4-STROKE
	RATED POWER(KW)		36.8
	FUEL		DIESEL
	RATED SPEED (R/MIN)		2400
	START		ELECTRIC
	ACCUMULATOR(V.AH)		12*100
STEERING ,BRAKE SYSTEM	STEERING TYPE		ITERNAL MESHING MULTICHIP
	BRAKE TYPE		WET FRICTION PLATE
TRANSMISSION SYSTEM	CLUTCH TYPE		DRY-FRICTION,SINGLE STAGE
	GEARBOX TYPE		CVT+VARIABLE SPEED (3 GEARS)
	GEAR SHIFT TYPE		HAND
TRAVELING SYSTEM	FRAME TYPE		RIGID FRAME TYPE
	TRACK	PITCHPITCH NO.WIDTH	9046350
	RANGE OF TRANSMISSION		CVT+VARIABLE SPEED(3 GEARS)
	TRAVELING SPEED (KM/H)	FIRST GEAR(F/R)	0-5.5
		SECOND GEAR(F/R)	0-7.6
		THIRD GEAR(F/R)	0-9.7
WORKING DEVICE	OIL PUMP MODEL		CBN310
	TILLING DEPTH CONTROL		HEIGHT ADJUSTABLE
	BORE*STROKE (MM)		80*100
	SUSPENSION TYPE		POSTPOSITION 3-POINT LINKS,CATEGORY I
	PTO ROTATING TYPE		NON-INDEPENDENT TYPE
	PTO ROTATING SPEED (R/MIN)		720/1000
	PTO ROTATING ROTATION DIRECTION		CLOCKWISE(FACE THE SHAFT)
	NUMBER OF SPLINE FOR PTO SHAFT		8
	SPLINE SIZE FOR PTO SHAFT (MM)		38
