Novo two for one twisting machine for short fibre, TFO twister

FOB Price

USD $1 - $2 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Item	Specification parameter
Machine type	Double face and single layer
Application range (Tex)	5×2~74×2
Suitable fibers	cotton, acrylic fiber, polyester and blends
Spindle pitch (mm)	Cotton 225, wool 265
Spindle number/group	16
Standard (max) spindle number	128 (240)
Spindle speed (max, rpm)	Cotton 15000, wool 10000
Twist range (T/m)	90-2800
Twisting direction	S & Z twist interchangeable
Feed package	Cotton 152×φ140, Wool 152×φ160
Winding bobbin	3°30’~5°57’ conical, parallel bobbin
Winding package (max,mm)	152×φ300
Changeable winding angle	16°30’, 19° ,21°30’
Winding tension	Adjusted by super feed roll
Spindle drive way	Single spindle drive
Change Spindle speed way	Frequency control speed
Spindle brake way	Electrical drive
Piecing way	Pneumatic piecing
Tensioner shape	Capsule
Motors	1 single spindle motor per spindle, 1 winding and traverse motors per set
Installed power (KW)	22 (0.16kw/spindle, traverse and winding 1.5kw)

Execllent yarn qulaity. The CV value varies between 1.5%-3.1%

Every spindle is pre-set and tested. Customers only need align the machines and connect them, which greatly reduces the installation time.

Each spindle is driven by its own motor, which saves a lot of power by:

1. no belt friction

2. spindle can start and stop on its own.

3. The actual power comsumption is lower than the belt-driven machine.

The NOVO twister runs with quite low noise because it avoids the friction in the belt system and touching in high speed running.

PAC control ensures user-friendly operation and more accurate control of the machine.
