3151AP absolute pressure transmitter
- shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | CEPAI | |
| Model Number | 3151AP |
Product Description
Range ratio: 40:1
Accuracy: range is 3, 4, 5
Range ratio is 1:1 to 10:1, ±0.1% of calibration range
Range ratio is 10:1 to 40:1, ±0.05(1+0.1URL/range)% of range
Range is 6, 7, 8, 9, 0
Range ratio is 1:1 to 10:1, ±0.15% of calibration range
Range ratio is 10:1 to 40:1, ±0.075(1+0.1URL/range)% of range
Stability: error in six months is ±0.15% of maximum range
Over pressure influence: error in six months is ±0.15% of maximum range after being added 140kgf/cm²
Power supply influence: less than 0.005%/V of output range
Vibration influence: frequency is 200Hz at any axial direction; error is ±0.05%/g of maximum range
Load influence: provided voltage input transmitter is higher than 12V, there will be no load influence within load working area
Mounting influence: maximum zero error is more than 0.25 kPa, but adjustable without influence to range, when you measure body, there will be no influence to flange rotary.
Model
3151AP | Intelligent Absolute Pressure Transmitter | |||||||||||
| code | Gauge pressure range(KPa) | Absolute pressure range(KPa) | |||||||||
1 | 0-0.15~7.5 | 0-0.15~7.5 | ||||||||||
2 | 0-4~40 | 0-4~40 | ||||||||||
3 | 0-2~200 | 0-2~200 | ||||||||||
4 | 0-7~700 | 0-7~700 | ||||||||||
5 | 0-21~2100 | 0-21~2100 | ||||||||||
6 | 0-70~7000 | 0-70~7000 | ||||||||||
7 | 0-210~21000 | 0-210~21000(special range is customized) | ||||||||||
8 | 0-420~41000(special range is customized) |
| ||||||||||
| code | Output | ||||||||||
A | 4-20mA standard output | |||||||||||
H | 4-20mA+HARTprotocol | |||||||||||
F | FF bus protocol | |||||||||||
| code | Flange joint | Vent valve | Isolation diaphragm | Filling | |||||||
22 | 316SS | 316SS | 316SS | Silicon oil (normal) | ||||||||
23 | 316SS | 316SS | Hastelloy C | |||||||||
24 | 316SS | 316SS | Monel | |||||||||
25 | 316SS | 316SS | Tantalum | |||||||||
33 | Hastelloy C | Hastelloy C | Hastelloy C | |||||||||
35 | Hastelloy C | Hastelloy C | Tantalum | |||||||||
44 | Monel | Monel | Monel | |||||||||
| code | Connection | ||||||||||
O | 1/4NPT F | |||||||||||
T | 1/2NPT F | |||||||||||
S1 | With one remote device(positive pressure side) | |||||||||||
| code | Display | ||||||||||
D | Digital head | |||||||||||
M | Digital head with set button | |||||||||||
N | Without head | |||||||||||
| code | Mounting bracket | ||||||||||
B1 | Bend bracket pipe mounting 2" | |||||||||||
B2 | Bend bracket plate mounting | |||||||||||
B3 | Flat bracket pipe mounting 2" | |||||||||||
| code | Explosion performance | ||||||||||
Ex | Explosion-proof | |||||||||||
id | Intrinsic-safety | |||||||||||
3151AP |
| |||||||||||
