Home > Products > CCTV DVR Kit > factory hot CE 8 channel mini 700tvl waterproof cctv camera dvr kit
factory hot CE 8 channel mini 700tvl waterproof cctv camera dvr kit
USD $120 - $140
/ Piece
10 Pieces(Min.Order)
- 5000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
-
factory best 4ch 700tvl p2p dvr kit, cloud new technology oem dvr system
-
HD sony cmos South America Hotsell 4CH 700TVL CCTV Security Kits
-
h.264 8ch hd ahd dvr combo cctv camera kit surveillance cctv security system
-
wholesale h.264 8ch realtime ahd dvr kit with 720p hd outdoor ahd bullet camera
-
Cheap Mini 4CH 1080N AHD DVR KIT AHD CAMERA
-
Shenzhen CCTV Factory 4 CH DVR KIT &Camera System
Product Details
| Place of Origin | Guangdong, China | Brand Name | Share-vision | |
| Model Number | XF6108S KIT |
Product Description
factory hot CE 8 channel mini 700tvl waterproof cctv camera dvr kit
1, cctv systems h.264
2, cctv 8ch dvr kit
3, security camera dvr kit
4. h.264 video compression
5. support HDMI
6. support PTZ
| Model# | XF-DVR6108 | ||
| Main Chip | Hi3520D | ||
| OS | Embedded Linux | ||
| Video/Audio input | CVBS input | 8channel | |
| BNC port(1.0Vp-p,75ohms),PAL/NTSC optional | |||
| Audio input | 1channel | ||
| RCA port | |||
| Talk back | YES | ||
| Video/Audio output | CVBS output | 1channel,BNC port(1.0Vp-p,75ohms) | |
| VGA | 1channel,1920×1080,1280×1024,1280×720,1024×768,800×600resolution optional | ||
| HDMI | Yes | ||
| Audio output | 1channel,RCA port | ||
| Video/Audio Encode | Real time surveillance resolution | D1 | |
| Video encode standard | H.264 | ||
| Encode resolution | D1,CIF optional | ||
| Highest encode ability | 4CH D1+4CH CIF real time | ||
| Video frame rate | 1~25 fps/PAL,1~30 fps/NTSC | ||
| Encode control | fixed code rate,variable code rate optional | ||
| Video rate | 48Kbps~2048Kbps | ||
| Stream type | video audio hybrid stream/video stream | ||
| Audio encode standard | G.711A | ||
| Audio rate | 64Kbps | ||
| Dual stream | Yes,CIF/QCIF optional | ||
| Video play back | 8channel palyback same time | ||
| Talk back | Two way audio talk back | ||
| Other | Motion detection | Each channel can support 396 (22×18)area detect | |
| area mask | 4 area for each channel | ||
| HDD | SATA port | 1*SATA | |
| External Interface | Network port | RJ45 10M/100M | |
| USB port | 2*USB2.0 | ||
| Alarm input/output port | NO | ||
| Structure | Dimension(unit size) | 215(L)x215(W)x45(H)mm | |
| Weight(whole) | 1.35Kg(without HDD) | ||
| Image Sensor | Color 1 / 3" CMOS |
| Lens | 3.6mm fixed Lens |
| IR LED | 24pcsF5 |
| Effective IR Distance | 25m |
| Compression Format | H.264 Multi-Streaming |
| Effective Pixels | PAL:512(H)×582(V)/NTSC:512(H)×492(V) |
| Horizontal Resolution | 700TVL |
| Signal System | PAL/ NTSC optional |
| Min illumination | 0.1Lux with IR On |
| S/N Ratio | ≥48dB |
| AGC | AUTO |
| White Balance | AUTO |
| Electronic Shutter | 1/50(60)——1/100,000(s) |
| Power Supply | DC12V |
| Power Consunption | 4W(When IR Leds ON) |
Packaging & Shipping
About Share-Vision:
| ShareVision: Professional manufacturer in the security and CCTV surveillance field. We had been in business of chipset supplying for over 10 years. |
| Certifications: ISO9001:2000, RoHS, CE and FCC |
| R&D team: more than 50 professional engineers |
| Warranty: 2 year for long term cooperation |
| With long term OEM service for customer mainly from EU, USA, South America and Africa, we will be your ideal choice for OEM Home / Office security. |
What we can do for you:
| 1. All units with brand logo when system start up. |
| 2. professional OEM packing with experience with UK and USA super market as the attached for reference. They are asking 1 whole product line from us. |
| 3. Certificate requested for Australia market ready for bulk order. |
| 4. flexible payment term as per your request. |
| 5. 1% spare part+ professional technical support as manufacturer |
