30 MW Nonmagnetic Retaining Ring
- Dalian Port
- T/T
You May Like
Product Details
| Place of Origin | Liaoning, China | Brand Name | Dingjiu | |
| Model Number | ESR | Application | Turbine generators | |
| Material | Stainless steel | Dimensions | 838*723*600 mm |
Product Description
Specifications
ASTM A289/A289M-97 Nonmagnetic retaining rings:Materials:
(1)1Mn18Cr18N (2)18Mn18Cr (3)P900 (4)50Mn18Cr5
(5)50Mn18Cr4W
1. Key component:
Nonmagnetic retaining ring is a critical component of heavy turbonator, one of the components bearing the highest stress, and by means of the retaining ring the centrifugal force is borne on the location of turning of the coil block on the both ends of the rotor.
2. Characteristics:
The retaining ring is hot assembled on the both ends of the rotors to compact the coils on the ends to prevent the coils of rotors during high speed operation from runaway damages which might cause disastrous accidents to the power stations.
3. Specification 1:
JB/T 1268-2002 in Chinese.
This is Specification for nonmagnetic retaining ring forgings for 50 MW to 200 MW turbine generators.
4. Specification 2:
JB/T 7030-2002 in Chinese.
This is Specification for nonmagnetic retaining ring forgings for 300 MW to 600 MW turbine generators.
5. Grades:
Unique heavy retaining ring presses are available in China and by them all the retaining rings with the specifications such as 3 MW – 1,000 MW grades are able to be manufactured.
