Micro Mylar Speaker Oblong P/N MD1318N-RC218
Negotiable
/ Piece
2000 Pieces(Min.Order)
- Shenzhen
- T/T
You May Like
-
For Micro Telephone Mobile Phone Receiver P/N SD20PH-RB19150-R6 (D20.0*H5.0)
-
Telephone Receiver Speaker For Mobile P/N SD21PH-04150 (D21.0*H3.8) with DIP pins for telecommunication
-
Micro Digit Transmitter And Receiver P/N: MSD15P-RB068 (D15.0*H4.2) with built-in receiver for mobile phones
-
Micro Receiver Dynamoelectric P/N SD13T-RB2132-R3 (D13.0*H3.6) for telecommunication
-
Micro Telephone Receiver Dynamoelectric Speaker P/N SD10T-RB1232 (D10.0*H4.5) for telecommunication
-
Micro Cell Phone Signal Receiver Dynamoelectric P/N SD10T-RB1232 (D10.0*H4.5) for telecommunication
Product Details
| Brand Name | WBN | Model Number | MD1318N-RC218 | |
| Use | Mobile Phone, Portable Audio Player | Place of Origin | Guangdong, China | |
Product Description
Specifications
Full range, with plastic frame oblong, ahesive gasket, for cellphonesSPECIFICATION DATA SHEET | |||
ITEM | DESCRIPTION | SPECIFICATION | TESTING CONDITION / REMARKS |
1 | Overall Size | W13*L18*H2.5 | |
2 | Impedance | 8 ohms | 8Ω± 15 % 2K Hz |
3 | Power Rated (Max.) | 0.5 W (in 1cc box) | 2.00 V |
4 | Sound Pressure Level | 92 +/-3 dB | @ 0.1m/Power Rated |
5 | Characteristic Sensitivity | 71 +/-3 dB | Calculated value equivalent to 1m/1W |
6 | Resonant Frequency(fo) | 20K Hz (SPL-15dB) | 0.3 V |
7 | Frequency Range | f0 ~ 20K Hz (SPL-15dB) | 0.3 V |
8 | Application | Communication | |
9 | Diaphragm | PET | |
10 | Frame | Plastic | |
11 | Magnet | NdFeB | |
12 | Weight | 1.8 g | |
13 | RoHs Compliant | Yes | |
14 | Packing Details | ||
15 | FEATURES | Slim with high power rated | |
