TUV MCS CEC certificated monocrystalline 240W solar panel

FOB Price

US$ 0.62 - 0.66 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

suntech solar panel
OSDA solar to provide best quality product to our customers with competitive price and excellent service

suntech solar panel suntech solar panel suntech solar panel

Specifications

Model Type	ODA255-30-M	ODA250-30-M	ODA245-30-M	ODA240-30-M	ODA235-30-M	ODA230-30-M
PeakPower(Pmax)	255	250	245	240	235	230
Maximum Power Voltage(Vmp)	30.54	30.48	30.42	30.36	30.32	30.3
Maximum Power Current(Imp)	8.35	8.20	8.05	7.91	7.75	7.59
Open Circuit Voltage(Voc)	37.27	37.2	37.1	37.02	36.98	36.95
Short Circuit Current(Isc)	9.03	8.96	8.80	8.64	8.47	8.3
Module Efficiency (%)	15.7	15.4	15.1	14.8	14.5	14.2
Maximum System Voltage (V)	1000
Maximum Series Fuse Rating (A)	15
Power Tolerance	0~+3%
Pmax Temperature Coefficients (W/°C)	-0.435%
Voc Temperature Coefficients (V/°C)	-0.35%
Isc Temperature Coefficients (A/°C)	0.043%
NOCT Nominal Operating Cell Temperature (°C)	47±2
Operating and Storage Temperature (°C)	-40~+85
Test Condition (STC)	1,000W/m2;AM 1.5;25°C

Mechanical characteristics & Packaging

Cell Type	mono-crystalline 156x156mm
No. of Cells	60(6x10)
Dimensions	1640x992x45mm
Weight	19.3kgs
Front Glass	3.2mm high transmission,low iron,tempered glass
Frame	Anodized Aluminium Alloy
Junction box	IP65 Rated
Output cables	TUV 1X4mm²,length 90cm
Quantity/pallet	23pcs
Loading Quantity	625pcs / 40ft

Structure of solar panel

Picture of solar panel
