0.35MP High Sensitivity USB Digital Microscope Eyepiece
Negotiable
/ Piece
20 Pieces(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
-
Economy Compact Usb Digital Microscope Eyepiece Camera
-
Digital LCD Microscope Monitor Camera Equipped With Wireless Remote Control MDC2000R
-
High Quality RoHS Proved 0.35MP USB Digital Microscope Digital Camera Equipped With Relay Lens
-
RoHS Proved 2.0MP MDA2000 Portable USB Digital Microscope
-
RoHS Proved MDA1300 Portable USB Microscope
-
RoHS Proved TP100 Telescope Digital Camera Equipped With Professional Imaging Software of Future Win Joe
Product Details
| Brand Name | Future Optics | Model Number | MSR350 |
Product Description
0.35MP Digital Image Sensor for Microscope is composed of matching optics system, image sensor and processing system, driver and application software. Special design in structure makes it compact in space and light in weight, and it is easy to connect with all kinds of microscope through the ocular tube or C-mount. Once the digital eyepiece is linked with PC, many excellent jobs will be done including images live showing, capturing, making movie, measuring and editing under the control of application software. Our Digital Eyepiece is a great device to upgrade traditional microscope into digital microscope and is of wide application in education, industry, agriculture, scientific research and medicine for its low cost and convenient operation.
Advantage:
1. Quality: To be of low power consumed, secure emission, innocuous environment relation.
2. Compatibility: To be suitable with all kinds of microscope.
3.ConnectionTo insert ocular tube.
4.Powerful softwareTo support display, capture, video in top resolution of chip.
5.To be compatible with Windows and Vista.
Features
Capture Mode | Picture and Video |
Max. Picture | 640*480 |
Max. Video | 640*480 |
Optics Magnification | 10X |
Eyepiece Adapter Size | 23.2mm, 30.0mm |
Power Supply | USB Powered |
Device Weight | 0.25kg |
Device Size | 93.0mm*60.0mm*25.0mm |
Cable length | 1.5m |
Function of Software | Image & video Capture, Edit and Management |
System Compatibility | 32bit and 64bit windows2000,XP,Vista, windows7 |
Language of software | English, French, German, Spanish, Japanese, Chinese, Russian |
PC Requirements | CPU: Inter Core2 2.8GHz or Higher; Memory: 2GB or More;USB Port:USB2.0 High-speed Port |
Specifications
Sensor Parameter | 1/4” 0.35MP |
Max. Resolution | 640*480 |
Pixel Size | 5.6µm*5.6µm |
Corresponsive | 1.9V/lux-sec |
Dynamic Range | 60dB |
S/N Ratio | 45dB |
Spectral Range | 400-650nm(with IR-filter) |
Frame Rate | 30fps@640*480 |
Proview Model | 640x480,352x288,320x240 |
Exposure | ERS or Manual |
Power Consumption | 70mW |
White Balance | Auto and manual |
Out Interface | USB2.0 |
