JDZ JDZJ-6 10 type voltage transformer

FOB Price

Negotiable / Piece

10 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	TUANJ
Model Number	JDZ JDZJ

JDZ, JDZJ-6, 10 type voltage transformer
1.ISO9001 factory
2.good quality and best price
3.voltage type

JDZ, JDZJ-6, 10 type voltage transformer

Technical data:

Type	Rated transformation ratio(A)	Accuracy class and rated output COSØ=0.8					Thermal limiting output(VA)	Rated insulation level(kV)
		0.2	0.5	1	3	3P 6P
JDZ-6(Q)	3000/100	15	30	50	80		200	3.6/24/40
	6000/100	20	50	80	200		400	7.2/32/60
JDZ-10(Q)	10000/100	30	80	120	300		500	12/42/75
	10000/200
	11000/100
JDZJ-6(Q)	3000/√3 100 /√3 100/3	15	30	50	80	100	200	3.6/24/40
	6000/√3 100/√3 100/3	20	50	80	200	100	400	7.2/32/60
JDZJ-10(Q)	10000/√3 100/√3 100/3	20	50	80	200	100	400	12/42/75
	11000/√3 100/√3 100/3

Note: any special requirements can be negotiate with us.
