YTF Type no Damage Cherry Sorting /grading Line/sieving Machine/sorting Machine/ Sorter/ Classifier/

Specifications

YTF type no damage cherry sorting machine

1. Brief introduction

   YTF type no damage cherry sorting machine is the latest development of our company in screening equipment. Use this equipment to do no injury classification to the cherry, completely solve problem of cherry loss and rot in separation process. The equipment can do water cooling to cherry in the classification process, directly packing and refrigerated after screening. Cherry’s temperature reduced, can extend its shelf life. Use mechanical classification can effectively improve the commercial quality of cherry.

2. Operation work principle

   YTF no damage cherry sorting machine, use cold water to be protect medium, cherry whole separation process in cold water medium, by this way, it can reduce the temperture of cherry, delay the time to be decay, also can remove the damage of cherry when separation process due to the collision damage.

   YTF no damage cherry sorting machine including loading part, human choose defective part, cleaning part, sorting part, medicine tank parts, packaging part. A complete set of equipment assembly line continuous production, control cabinet centralized control.

   The equipment function can be sorting out different level and weight cherry, according to the size and weight, leave off by different ers can directly loading, weighing and packing. Separation process can also do defective choose to cherry.

3. Equipment technical parameters

  Sorting production: 2.5 tons/hour.

  Sorting level: 4-5 levels (customized);

  Sorting diameter range: 10-40 mm (adjustable);

  Refrigeration temperature: water temperature 5-15 degrees;

  Power supply: 380/220 v;

  Total power: 28.7 kW; (including refrigerating machine)

  Floor area :16.5×15 m
