Hight efficiency 1200w 12V/24V/36V/48V led switching power supply

FOB Price

US$ 199 - 237 / Piece

1 Piece(Min. Order)

Port ningbo/shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	ueone
Model Number	s-1200-36	Output Power	Other, >500W
Output Type	Single	Input Voltage	220V
Output Voltage	0-36V	Output Frequency	dc
Output Current	33A

Product Description

Reliable0-36v 33A 1200w switch power supply atx

Welcome,my friend! Glad to introduce 1200w 0-36V 33A adjustable switching power supply CE factory price S-1200-36. If you have any questions, please don't hesitate to ask me.

MY SKYPE: alicewang233

product feature

1. AC input range 200vac to 240vac 50/60HZ

2. Protections: Short circuit / Overload / Over voltage

3. 100% full load burn-in test

4. Low cost, high reliability

5. 24 months warranty

6. high efficiency

product show

product parameter

SPECIFICATIONS
OUTPUT
Model	S-1200-		S-1200-12	S-1200-24	S-1200-36	S-1200-56		S-1200-60		S-1200-110	S-1200-220
DC Voltage	0		12V	24V	36V	56V		60V		110V	220V
Rated Current	0		100A	50A	33A	21A		20A		11A	5.5A
Current Range	0		0-100A	0-50A	0-33A	0-21A		0-20A		0-11A	0-5.5A
Rated Power	0		1200W	1200W	1200W	1200W		1200W		1200W	1200W
Ripple & Noise	150mVp-p		150mVp-p	150mVp-p	150mVp-p	150mVp-p		150mVp-p		200mVp-p	240mVp-p
Voltage Adj. Range	-10%,+12%		±20%	-16%,+10%	-12%,+11%	-10%,+20%		-16%,10%		-4%,+18%	-15%,+17%
Voltage Tolerance	±2%		±2%	±1%	±1%	±1%		±1%		±1%	±1%
Setup, Rise, Hold Up Time	200ms,50ms,20ms at full load
INPUT
Voltage Range	180~264VAC
AC Current	6.5A/115V 4A/230V UEONE FACTORY
Efficiency	73%	76%		74%	79%		78%		81%	82%	83%
Inrush Current	Cold start 50A/115V 50A/230V
Leakage Current	<3.5mA/240VAC
PROTECTION
Over Load	105%~135%
	Protection type: Fold back current limiting, recovers automatically after fault condition is removed.
Over Voltage	115%~135%
	Protection type: hiccup mode, recovers automatically after fault condition is removed.
Over Temp.	RT3≥55 Fan On, ≤45 Fan Off, ≥80 Output Shutdown (5~7.5V)
	RT3≥65 Fan On, ≤55 Fan Off, ≥80 Output Shutdown (12~15V)
	RT3≥70 Fan On, ≤60 Fan Off, ≥85Output Shutdown (24~48V)
ENVIRONMENT
Working Temp., Humidity	-10~+50; 20%~90%RH
Storage Temp., Humidity	-20~+85; 10%~95%RH
Vibration	10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes
SAFETY
Withstand Voltage	I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
STANDARD
Safety Standard	Design refer to UL1950
EMC Standard	Design refer to EN55022, EN55024, EN61000
OTHERS
Dimension	30016097mm(LWH)
Weight	4Kg

mechanical specifica

notes for use
