Home > Products > adjustable power supply > 1200W High smps power supply 220Vac to 110V 11a dc power supply s-1200-110
1200W High smps power supply 220Vac to 110V 11a dc power supply s-1200-110
- ningbo/shanghai
- T/T
You May Like
-
Hight efficiency 1200w 12V/24V/36V/48V led switching power supply
-
0-36v 20a adjustable switching power supply 720W 36V adjustable power supply SW-720-36
-
0-72V 1500W Regulated adjustable switching power supply 72V20A voltage adjustable power supply
-
Ueone 0-144V 3000W regulated adjustable DC power supply 144v 20A switching power supply
-
4 channels cctv power supply
-
security cctv camera power supply 12V 10Amp 9ch power supply
Product Details
| Place of Origin | Zhejiang, China | Brand Name | ueone | |
| Model Number | s-1200-110 | Output Power | Other, >500W | |
| Output Type | Single | Input Voltage | 220V | |
| Output Voltage | 0-110V | Output Frequency | dc | |
| Output Current | 11A |
Product Description
Reliable0-110v 11A 1200w switch power supply atx
Welcome,my friend! Glad to introduce 1200w 0-110V 11A adjustable switching power supply CE factory price S-1200-110. If you have any questions, please don't hesitate to ask me.
MY SKYPE: alicewang233
1. AC input range 200vac to 240vac 50/60HZ
2. Protections: Short circuit / Overload / Over voltage
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty
6. high efficiency
| SPECIFICATIONS | |||||||||||
| OUTPUT | |||||||||||
| Model | S-1200- | S-1200-12 | S-1200-24 | S-1200-36 | S-1200-56 | S-1200-60 | S-1200-110 | S-1200-220 | |||
| DC Voltage | 0 | 12V | 24V | 36V | 56V | 60V | 110V | 220V | |||
| Rated Current | 0 | 100A | 50A | 33A | 21A | 20A | 11A | 5.5A | |||
| Current Range | 0 | 0-100A | 0-50A | 0-33A | 0-21A | 0-20A | 0-11A | 0-5.5A | |||
| Rated Power | 0 | 1200W | 1200W | 1200W | 1200W | 1200W | 1200W | 1200W | |||
| Ripple & Noise | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | |||
| Voltage Adj. Range | -10%,+12% | ±20% | -16%,+10% | -12%,+11% | -10%,+20% | -16%,10% | -4%,+18% | -15%,+17% | |||
| Voltage Tolerance | ±2% | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | |||
| Setup, Rise, Hold Up Time | 200ms,50ms,20ms at full load | ||||||||||
| INPUT | |||||||||||
| Voltage Range | 180~264VAC | ||||||||||
| AC Current | 6.5A/115V 4A/230V UEONE FACTORY | ||||||||||
| Efficiency | 73% | 76% | 74% | 79% | 78% | 81% | 82% | 83% | |||
| Inrush Current | Cold start 50A/115V 50A/230V | ||||||||||
| Leakage Current | <3.5mA/240VAC | ||||||||||
| PROTECTION | |||||||||||
| Over Load | 105%~135% | ||||||||||
| Protection type: Fold back current limiting, recovers automatically after fault condition is removed. | |||||||||||
| Over Voltage | 115%~135% | ||||||||||
| Protection type: hiccup mode, recovers automatically after fault condition is removed. | |||||||||||
| Over Temp. | RT3≥55 Fan On, ≤45 Fan Off, ≥80 Output Shutdown (5~7.5V) | ||||||||||
| RT3≥65 Fan On, ≤55 Fan Off, ≥80 Output Shutdown (12~15V) | |||||||||||
| RT3≥70 Fan On, ≤60 Fan Off, ≥85Output Shutdown (24~48V) | |||||||||||
| ENVIRONMENT | |||||||||||
| Working Temp., Humidity | -10~+50; 20%~90%RH | ||||||||||
| Storage Temp., Humidity | -20~+85; 10%~95%RH | ||||||||||
| Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes | ||||||||||
| SAFETY | |||||||||||
| Withstand Voltage | I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | ||||||||||
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC | ||||||||||
| STANDARD | |||||||||||
| Safety Standard | Design refer to UL1950 | ||||||||||
| EMC Standard | Design refer to EN55022, EN55024, EN61000 | ||||||||||
| OTHERS | |||||||||||
| Dimension | 300*160*97mm(L*W*H) | ||||||||||
| Weight | 4Kg | ||||||||||
The 5 layers corrugated empty carton can bear 1 person pressure ,
you can rest assured about our fixed package
we use 4 trips to reinforce our carton,the international standards package methods
guaranteed our goods safety during transportation
we can shiped the goods by EMS DHL FEDEX UPS AIR SEA SF TNT
Notes on choosing a switching power supply?
To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.
- What are switching power supplies?
- Switching power supplies input a commercial AC power supply (such as 110 VAC or 220 VAC), uses a high-speed semiconductor switching process to convert the input to high-frequency electric power, and yields a direct current (such as 24 VDC).
