Home > Products > Minerals & Metallurgy > High Chromium Gringding Ball Apply for Power Plant in Good Quality and Vary Low Breakage Rate
High Chromium Gringding Ball Apply for Power Plant in Good Quality and Vary Low Breakage Rate
- Qingdao Port
- T/T
You May Like
-
ISO Approved Led Mesh Screen With Low Price /T
-
Forged and Casting Grinding Steel Ball With High Hardness Made in China for Mineral Processing and Cement Plant
-
High Hardness Steel Grinding Ball With High Hardness Used for Mine & Cement Plant & Power Station
-
CNBM Garden Insect Mesh With High Quality /T
-
Trendy Fine Mesh Window Screen Packed in Opp Bag
-
High Chromium Gringding Ball With High Hardness and Resistance, Top Quality For Cement and Mine
Product Details
| Brand Name | CMAX | Model Number | CMAX-2 | |
| Application | To be the milling media in Power Plant & Mineral Processing | Dimensions | DIA 20mm-150mm |
Product Description
1. Specification of High Chromium Cast Alloyed Grinding Ball for Power Plant and Mineral Processing
1. Diameter: 20mm-150mm
2. Grade: 22Cr, 17Cr, 15Cr, 11Cr, 5Cr, 1.5Cr, etc
3. Chemical composition: C, Si, Mn, Cr, P, S, Mo, Cu, Ni, etc
4. Surface treatment: burnt sand & smooth.
5. It is free from hard spot, visible injurious defects such as blow hole,porosity, shrinkage, cracks, cold-shuts.
2. Size of High Chromium Cast Alloyed Grinding Ball for Power Plant and Mineral Processing
Norminal Diameter | Theorial Diameter | Theorial Weight | Surface Hardness | Core Hardness |
(mm) | (mm) | (kg/per piece) | (HRC) | (HRC) |
20 | 20.8 | 0.037 | 62-65 | 62-65 |
25 | 28.0 | 0.072 | ||
30 | 31.2 | 0.125 | ||
35 | 36.4 | 0.198 | 62-65 | 61-64 |
40 | 41.6 | 0.296 | ||
45 | 46.8 | 0.421 | ||
50 | 52.0 | 0.578 | ||
55 | 57.2 | 0.769 | ||
60 | 62.4 | 0.999 | ||
65 | 67.6 | 1.270 | 60-63 | 59-62 |
70 | 72.8 | 1.586 | ||
75 | 78.0 | 1.951 | ||
80 | 83.2 | 2.367 | ||
85 | 87 | 2.5243 | 59-64 | 59-64 |
90 | 92 | 2.9964 | ||
95 | 97 | 3.5241 | ||
100 | 102 | 4.1103 | ||
105 | 107 | 4.7582 | ||
110 | 112 | 5.4710 | ||
115 | 118 | 6.2512 | 58-63 | 58-63 |
120 | 122 | 7.1026 | ||
125 | 127 | 8.0279 | ||
130 | 133 | 9.0303 | 58-63 | 57-63 |
135 | 138 | 10.1076 | ||
140 | 143 | 11.2728 | ||
145 | 148 | 12.5243 | ||
150 | 153 | 13.8651 |
3. Features of High Chromium Cast Alloyed Grinding Ball for Power Plant and Mineral Processing
Composition (%) | C | Si | Mn | Cr | P | S | Hardness (HRC) | Wear Rate in Gold Mine |
Low Cr Cast Balls | 2.0~3.0 | 0.5~1.5 | ≤0.50 | 1.5~2.5 | ≤0.07 | ≤0.07 | 46~55 | About 1000g/MT |
Mid Cr Cast Balls | 2.0~3.5 | ≤1.0 | 0.3~1.2 | 4.0~6.0 | ≤0.10 | ≤0.10 | ≥50 | About 870g/MT |
Cr12 Cast Balls | 2.0~3.0 | ≤1.2 | 0.7~2.0 | 10~12 | ≤0.06 | ≤0.06 | ≥55 | ≤820g/MT
|
Cr15 Cast Balls | 2.0~3.0 | ≤1.2 | 0.7~2.0 | 14~16 | ≤0.06 | ≤0.06 | ≥58 | |
Cr20 Cast Balls | 2.0~3.5 | ≤1.0 | 0.5~1.5 | 17~23 | ≤0.06 | ≤0.06 | ≥60 | ≤760g/MT |
