Home > Products > Air-conditioner capacitors > Cbb65 Capacitor Mfd
Cbb65 Capacitor Mfd
US$ 0.156 - 0.672
/ Piece
1000 Pieces(Min. Order)
- Shunde port
- T/T
You May Like
-
Oil Filled Capacitor Cbb65
-
Air Conditioning Capacitor Cbb65 Air Conditioner Capacitor
-
Vac Capacitor Cbb65
-
ul Approval Capacitor Cbb65 Motor Running Capacitor Cbb65 Capacitor
-
Refrigerator Capacitor Cbb65 Air Conditioner Capacitor ac Capacitor
-
CBB65 UL Capacitor Air-conditioner UL Capacitor Cbb65 Capacitor 25uf
Product Details
| Place of Origin | Guangdong, China | Brand Name | Dahua | |
| Model Number | CBB65 | Type | Polypropylene Film Capacitor | |
| Application | General Purpose | Package Type | Other, Vegetable oil | |
| Capacitance | 5~100uF | Rated Voltage | 250VAC/370VAC/450VAC/630VAC | |
| Operating Temperature | -40/+85 |
Product Description
Specifications
We are professional in producing cbb65 capacitor mfd,film capacitor,motor capacitors.Used in airconditioners.We are professional in producing cbb65 capacitor mfd ,film capacitor,motor capacitors,which are used in compressors for airconditioners.
Product Description
1.The feature is small in dimension, high capacitance, low dissipation factor, antiexplosive device and safety reliability.
2.The motor capacitors body is convoluted with metallized film.
3. The container is adoptted aluminum or other metal material. It is enveloped with capacitor oil, capacitor gule or epoxy resin, etc. (Non PCB).
4. The install part is screw at bottom of container or decided by clients.
5. Connection terminals: 250# terminal, plastic-sealed wire, etc.
| Type | Ambient Temperature (ºC) | Rated voltage ( VAC ) | Rated capacitance (μ F ) | Test voltage ( VAC ) | Insulation Resistance | Dissipation Factor | Satety Test |
| CBB65 | -40~+70ºC | 250~630 | 5~80 | T-T:1.5Un/60S 2 .0 Un/10S | T-T: ≥ 3000S | tg δ≤ 0.002 (100Hz) | Germany VDE EN60252 ( P2) USA UL810 CYWT2 |
| T-C:2000VAC/60S | T-C: ≥ 1000M Ω |
